Supply Carry-Home Blood Analysis Machine
Specifications
Model |
TE-3000 |
Parameters |
23Parameters 20+3histogram |
Principles |
Impedance |
Sample volume |
20μl venous blood or capillary |
Sample processing |
Open tube |
Aperture Diameter |
WBC 80um RBC/PLT 80um |
Dilution Rations |
Whole blood 1-500, Capillary Blood 1-250 |
|
Whole blood 1-40000 Capillary Blood 1-40000 | |
Data storage |
20000 test results with histogram |
Throughput |
60 samples/hour |
Display |
8 inch colour LED |
Carryover |
WBC,RBC,HGB≤0.5%,PLT≤1% |
Aperture |
Double apertures for WBC and RBC/PLT |
Patented aperture technology |
Automatic block-clearing of high pressure and lower rate of block |
Printout |
built-in the thermal printer(optional external printer) |
input/outpout |
one RS232,1keyboard,1USB,1printer port |
Operating environment |
Temperature 15°C-30°C,Humidity 30%-85% |
Power requirment |
100-240V~50/60Hz |
Dimension |
440(W)*354(D)*430(H) |
Weight |
17KG |
Features
Working methods: |
Electrical impedance method, cyanide methemoglobin method and non-cyanide SFT method |
Test Parameters |
WBC three categories, 22 parameters, 23 parameters (including color histograms of WBC, RBC, PLT) |
Specimen Amount: |
Whole blood: 9.6μL; peripheral blood(direct detection): 9.6μL; peripheral blood (pre-dilution mode): 20μL |
Test Speed: |
Single-channel: 30 samples/h, dual-channel: 60 samples/h. May be continuous 24 hours a day, with automatic sleep and wake functions |
Results Storage: |
The device saves 1.2 million copies of the results with all three histograms automatically |
Quality Control Methods |
L-J graph, X, SD, CV% |
Automatic detection reagent margin, closed reagent tube | |
Calibration: |
Manual calibration and automatic calibration |
Reference Value Setting: |
8 settings groups with adult male, adult female, child, newborn, general all purpose and 3 groups of custom settings |
Information: |
The device supports a variety of multiple patient information fast Chinese input, including 12 kinds of information such as name, department and censorship. |
Interface: |
A parallel printer interface, a VGA display interface, two RS-232 interfaces, two USB interfaces and two PS / 2 interfaces |
Report Printing: |
Built-in high thermal printing, optional six reporting formats in English, and an optional external printer |
Working Environment: |
Working temperature of 15-35°C, and can be used in high altitude environment |
Power supply: |
AC 220V 50HZ |
Operation: |
Chinese Windows color operating system, graphical buttons, supporting mouse operation |
