Home > Products > hematology analyzer > laboratory 3 part automatic blood cell counter hematology analyzer
laboratory 3 part automatic blood cell counter hematology analyzer
USD $1 - $5,000
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- Guangdong
- T/T Credit Card PayPal
You May Like
Product Details
| Type: | Blood Analysis System | Brand Name: | Joyful | Model Number: | GY-518D |
| Place of Origin: | Guangdong, China |
Product Description
Laboratory 3 part automatic
blood cell counter hematology analyzer
Product Description
Joyful's laboratory 3 part automatic blood cell counter hematology analyzer is use for prescisely testing read blood cells, platelets and white blood cells It is widely using in hostpital to help doctors get credible diagnosis clue.
Feature
- 3 part differentiation, 20 parameters +3 histograms
- Double apertures for WBC and RBC/PLT separately
- Whole blood and pre-diluted counting modes available for different patients' sample requirement
- 60 samples/hour throughput
- Storage capability of up to 20000 sample results with histograms
- External keyboard, optional barcode scanner, printer port and other enhanced functio
Technical parameter
| 1.How It Works | Electrical impedance method, cyanide met hemoglobin method and non-cyanide SFT method |
| 2.Test Parameters | WBC three categories, 22 parameters, 23 parameters (including color histograms of WBC, RBC, PLT) |
| 3.Specimen Amount | Whole blood: 9.6μL; peripheral blood(direct detection): 9.6μL; peripheral blood (pre-dilution mode): 20μL |
| 4.Test Speed | Single-channel: 30 samples/h, dual-channel: 60 samples/h. May be continuous 24 hours a day, with automatic sleep and wake functions |
| 5.Results Storage | The device saves 1.2 million copies of the results with all three histograms automatically |
6.Quality Control Methods | L-J graph, X, SD, CV% |
| 7. Automatic detection reagent margin, closed reagent tube | |
| 8.Calibration | Manual calibration and automatic calibration |
| 9.Reference Value Setting | 8 settings groups with adult male, adult female, child, newborn, general all purpose and 3 groups of custom settings |
| 10.Information | The device supports a variety of multiple patient information fast Chinese input, including |
| 11.Operation | Chinese Windows color operating system, graphical buttons, supporting mouse operation |
| 12.Interface | A parallel printer interface, a VGA display interface, two RS-232 interfaces, two USB interfaces and two PS / 2 interfaces |
| 13.Report Printing | Built-in high thermal printing, optional six reporting formats in English, and an optional external printer |
| 14.Working Environment | Working temperature of 15-35°C, and can be used in high altitude environment |
| 15.Power supply | AC 220V 50HZ |
Specification
| Model | TE-3000 |
| Parameters | 23Parameters 20+3histogram |
| Principles | Impedance |
| Sample volume | 20μl venous blood or capillary |
| Sample processing | Open tube |
| Aperture Diameter | WBC 80 μm RBC/PLT 80μm |
| Dilution Rations | Whole blood 1-40000 Capillary Blood 1-40000 Whole blood 1-500 Capillary Blood 1-250 |
| Data storage | 20000 test results with histogram |
| Throughput | 60 samples/hour |
| Display | 8 inch colour LED |
| Carryover | WBC,RBC,HGB≤0.5%,PLT≤1% |
| Aperture | Double apertures for WBC and RBC/PLT |
| Patented aperture technology | Automatic block-clearing of high pressure and lower rate of block |
| Printout | built-in the thermal printer(optional external printer) input/output one RS232,1keyboard,1USB,1printer port |
| Operating environment | Temperature 15°C-30°C,Humidity 30%-85% |
| Power requirement | 100-240V~50/60Hz |
| Dimension | 440(W)*354(D)*430(H) |
| Weight | 17KG |
Our Services
Warranty
- We offer one year free maintenance for this type of machine
- On-line services in time.
- We guarantee quick and efficient service and maintenance of our device security solutions around the world
Packaging & Shipping
| Delivery | 1 - 7 working days |
| Packaging | Carton box, or as per customers instruction |
| Payment | L/C / T/T / Western Union |
Company Information
Guangzhou Joyful Technology Co., Ltd is a professional medical equipment manufacturer, It is a branch of Joyful group. It is a high-tech enterprise with independent intellectual property rights, specializing in the development, production and sale of medical equipment.
