portable medical laboratory blood test equipment
| Feature |
|
-3-part differentiation of WBC; 20 parameters and 3 color histograms (WBC, RBC, PLT) -Work mode : Double Channel + unique Hemoglobin test system -Throughput: 60 Samples/H -Automatic diluting , Mixing , rinsing and clog clearing -Automatically sample probe cleanning (inside and outside) |
Specification |
|
-Methodology: Electrical resistance for counting, hemiglobincyanide method and SFT method for hemoglobin -Test Parameters: WBC, LYM#, MID# ,GRAN#, LYM% MID%,GRAN% ,RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV ,PDW ,PCT ,PLCR and 3- Histograms WBC,RBC,PLT -Sample volume: 9.6μL for Venous and capillary mode, 20μL for pre-dilution mode -QC control : X-B, L-J, X , SD, CV % -Sampling mode: Venous mode ,Capillary mode, Pre-dilution mode -Storage: up to 100000 sample results including histograms can be stored, convenient for inquiry and management of history data -Print : Graphic thermal printer with various printing format -Ref. Value Setting : Male , Female, Children, Neonate |
| Operation Unit |
|
- Windows operation system -Input / output : RS232, parallel printer and keyboard optional external printer - Operation langue: English - Internal thermal printer or external printer |
| Precision |
|
Parameters Linear range CV %
WBC( 10 9 / L ) 0.0 - 99.9 ≤2%
RBC ( 1012 / L ) 0.0 - 9.99 ≤1.5%
MCV ( fL ) 40-150 ≤0.5%
PLT ( 10 9 / L ) 0-999 ≤4.0%
HGB( g/L ) 0.0-300.0 ≤1.5%
Cross contamination: RBC,WBC,HBC <0.5% PLT<1% |
| Working Conditions |
|
-Room Temperature : 18°C - 30°C, -Humidity ≤ 10-90% -Power supply : 220 V ±22 VAC, 50±1Hz |
Packing |
|
-Dimension : 33 CM ( L ) * 38 CM ( W ) * 43 CM ( H )
-Weight : 20 KGS |
