Home > Health & Medicine > Medical Equipment > Ultrasonic, Optical, Electronic Equipment > Design Hot Selling Mini Portable Ecg Machine Price PM-8000

Design Hot Selling Mini Portable Ecg Machine Price PM-8000

Name: Design Hot Selling Mini Portable Ecg Machine Price PM-8000
Brand: Joyful, JOYTEC
SKU: 135480957
Availability: InStock

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 thumbnail-1

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 thumbnail-2

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 thumbnail-3

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 thumbnail-4

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 thumbnail-5

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 thumbnail-6

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 photo-1

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 photo-2

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 photo-3

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 photo-4

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 photo-5

Design Hot Selling Mini Portable Ecg Machine Price PM-8000 photo-6

US$ 250 - 250 MOQ: 1 Piece

Key Specifications

Get Latest Price

Type:

Other, Medical Micro-Devices, Medical Micro-Devices

Brand Name:

Joyful, JOYTEC

Model Number:

pm-8000

Contact Supplier Request Quote Chat Now

Guangzhou Joyful Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Other, Medical Micro-Devices, Medical Micro-Devices

Brand Name Joyful, JOYTEC

Model Number pm-8000

Place of Origin Guangdong, China

Product Description

Design hot selling mini portable ecg machine price PM-8000

1. Model: PM-8000

2. Working theory

The system can transform biomedical signal into electric signal through signal detection and reprocess Module, at the same time preprocess interference suppression, signal filtering and amplification and so on.Then it will
conduct a computational analysis to the parameters after the sampling and quantification through data extraction and Preprocess Module. The results will be monitor and compared to threshold value, which may lead to an Alarm. The result date will be stored to RAM in real time, which can be transmitted to a PC. The PC can show all the
parameter values in real time.

3.Breif Introduction

As a multi-functional ECG machine, mobile ECG include functions about auscultation, ECG acquisition,

SpO2 and pulse rate monitoring. This instrument has ECG waveform recording and playback; oxygen

value and pulse rate value could be stored and data will be uploaded to a computer to facilitate analysis of the disease.

Applicable For: hospital, community health, oxygen bar, family, before and after exercising,
etc.

4.Main Parameters

(1) Measurement of auscultation volume		Lung sound range: 100Hz~800Hz Heart lung combination sound range: 20Hz~800Hz
(2) Measurement of Heart Rate		Range: 30bpm~300bpm Resolution: 1bpm Accuracy: ±2bpm or ±2%(select larger)
(3) Measurement of SpO2		range: 0%~100% resolution: 1% accuracy: When the SpO2 measurement range is 70%~100%, the permission of absolute error is ±2%. Below 70% unspecified.
(4) Measurement of pulse rate		Range: 30bpm~250bpm Resolution: 1bpm Accuracy: ±2bpm or ±2%(select larger)
(5) Measurement Performance in Weak filling Condition		SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%, SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2%(select larger).
(6) Resistance to surrounding light		The deviation between the value measured in the condition of man-made light and indoor natural light and that of darkroom is less than ±1%.

5. Main function

1)Compact and portable, easy to use
2)Display of ECG waveform, heart rate, SpO2, pulse rate, pulse waveform
3)Earphone output and 16 steps volume adjustable

4)Alarm for SpO2 and pulse rate exceeding limits
5)Real-time detecting, TF card data record and review
6)Real-time clock
7)Recorded data can be transferred to a PC
8)PC analysis software
9)Low power consumption

6.Main Advantages

1)Easy to operate.

2)Newest piezoelectric sensors
3)Button volume control
4)3 types auscultation mode: heart sound, lung sound, h5)eart and lung sound
6)Color TFT, resolution: 160*128

7)ECG waveform display
8)SpO2, pulse oximeter display
9)3.7V lithium battery

7.Unique characteristics

1.Portable design with small size and light weight
2.Earphone output with adjustable VOL16
3.Alarm for over-limit SpO2 and pulse rate
4.Real time monitoring, data storage and

cineloop

5.Uploadable recording data
6.PC date analysis software
8.Low power consumption

Detailed Images

Technical specifications
Physical Characteristics		Size: 110(length)60(wicth)15(height)mm Weight:100(including lithium battery)
Environment Transport and storage		Temperature: -10℃~ +50℃ Relative Humidity: 10% ~ 95% Atmospheric pressure: 50kPa ~ 106Kpa
Working environment		Temperature: 5℃~40℃ Relative Humidity: 20%~80% Atmospheric pressure: 70kPa~106kPa
Battery type		charging lithium battery
Working-voltage		DC3.6V~DC4.2V
Power		≤120mA
LCD display		2.4"TFT, 320*240 Pixels
Continuous running time		7hours

Our Service

Warranty

Free maintenance: 1 years for mainframe
Safety device solutions for any product
Free Software update
Hardware fitting replacement
We will offer an assitance to maintan the machine if there are any breakdown happen
24 hours online serivce
Quick and efficient service and maintenance of our product

Packing&Shipping

All items are exported by standard wooden packing with alloy frame. Machine will be complete accommodating in it properly.

Company

About our company:

Guangzhou Joyful Technology Co., Ltd. is a high-tech enterprise with independent intellectual property rights, specializing in the development, production and sale of medical and health products.

Joyful Tech is a company founded on innovation, accompanied by an enduring commitment to customer service and an unwavering dedication to improving patient care.with a mission to deliver high-quality competitively priced medical device.

Our factory is equipped with perfect testing equipment. Everything runs under strict quality control systems to ensure the high quality and competitive prices of our products. Our products consistently meet CE and other international standards.
