2016 Portable Electronic Stethoscope Price of Ecg Machine With CE

2016 Portable Electronic Stethoscope Price of Ecg Machine With CE thumbnail-1
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE thumbnail-2
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE thumbnail-3
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE thumbnail-4
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE thumbnail-5
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE photo-1
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE photo-2
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE photo-3
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE photo-4
2016 Portable Electronic Stethoscope Price of Ecg Machine With CE photo-5
US$ 250 - 250 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Medical Micro-Devices
Brand Name:
Joyful, JOYTEC
Model Number:
pm-8000
Contact Supplier Request Quote Chat Now
Guangzhou Joyful Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Medical Micro-Devices
Brand Name Joyful, JOYTEC
Model Number pm-8000
Place of Origin Guangdong, China
Product Description

2016 portable electronic stethoscope price of ecg machine with CE


PM-8000 is a kind of multi-functional visual stethoscope.It integrates the functions of auscultation,ECG collection,SpO2 and PR inspection.The product is applicable for hospital, community medical treatment, oxygen station, family, sport health care, etc.


Main Features


■ Compact and portable, easy to use
■ Display of ECG waveform, heart rate,SpO2 ,pulse
 rate ,pulse waveform
■ Earphone output and 16 steps volume adjustable
■ Alarm for SpO2 and pulse rate exceeding limits
■ real-time detecting, TF card data record and
review
■ Real-time clock
■ Recorded data can be transferred to a PC
■ PC analysis software
■ Low power consumption
■ Operation of the product is simple and
convenient.
Detailed Images


Technical specifications

.


Physical
Characteristics
Size
110(length)*60(wicth)*15(height)mm
Weight
100(including lithium)

Environment
Transport and
storage
Temperature
Relative Humidity
10% ～ 95%
Atmospheric pressure
50kPa ～ 106Kpa




Working
environment
Temperature
5℃～40℃
Relative Humidity
20%～80%
Atmospheric pressure
70kPa～106kPa
Battery type
charging lithium battery
Working-viktageL
DC3.6V～DC4.2V
Power
≤120mA
LCD display:
2.4＂TFT, 320*240 Pixels
Continuous running time
7hours

Main Parameters:
(1) Measurement of auscultation volume
Heart sound range: 20Hz～230Hz
Lung sound range: 100Hz～800Hz
Heart lung combination sound range: 20Hz～800Hz
(2) Measurement of Heart Rate
Range: 30bpm～300bpm
Resolution: 1bpm
Accuracy: ±2bpm or ±2%(select larger)
(3) Measurement of SpO2
range: 0%～100%
resolution: 1%
accuracy: When the SpO2 measurement range is 70%～

100%, the permission of absolute error is ±2%. Below

70% unspecified.
(4) Measurement of pulse rate
Range: 30bpm～250bpm
Resolution: 1bpm
Accuracy: ±2bpm or ±2%(select larger)
(5) Measurement Performance in Weak filling Condition
SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%, SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2%(select larger).
(6) Resistance to surrounding light
The deviation between the value measured in the

condition of man-made light and indoor natural light and that of darkroom is less than ±1%.

Our Service

Safe Guarantee


There is 24 hours online service, as the world's professional medical device manufacturers, we guarantee quick and efficient service and maintenance of our device security solutions whatever and whenever you need us.

Packing & Delivery
Packing & Delivery
Delivery
3 - 7 working days
Packaging
Carton box
Payment
L/C / T/T / Western Union
Our Company


Our company is a company founded on innovation,accompanied by an enduring commitment to customer service and dedication to improving unwavering dedication to improving patient care.with a mission to deliver high-quality competitive priced medical device.Our products consistently meet CE and other international standards. OEM and ODM orders are acceptable.

Certifications

Everything runs under strict quality control systems to ensure the high quality and competitive prices of our products. Our products consistently meet CE and other international standards.
