Pigmented Spot Removal E Remove Tiny Wrinkle Light(IPL+RF) 2.6MHZ

Applications:

Skin rejuvenation: pores refining, improve rough, dark and gloomy skin, restore skin elasticity

Pigment treatment: freckles, sun-burn spots, senile plaque, pigmentation spots

Hair removal: armpit, chest, lip, arms, legs, beard, bikini etc.

Vascular, spider angioma, acne rosacea

Acne: pimples, improve seborrheic oily skin and acne scars

Specifications



Product Description

Specifications:

Light Source:	Intense Pulsed Light
Head	One E light handle, 5 filters for this handle One Bi-polar RF handle, 3 tips for this handle
1)Wavelength:	430nm, 480nm, 560nm, 590nm, 640nm(or 690,others)
2)Spot size:	8x40mm (13x30mm,15x50mm)
3)IPL light energy:	1-50J/cm²
4)Pulse number	1-15
5) RF energy	1-50J/cm²
6)Pulse Duration:	1-20ms
7)Pulse Sequence:	1-6 pulses
8)Delay Time	1~50ms
9)IntegratedSkin  Cooling:	-4°C~+2°C
10) Controller	8.4 inches color touch screen
11)RF Drive power	300W
12) IPL Drive Power	1500W
13)RF Frequency	10MHZ
14)Working Period	Continuously stand-by working for 14 hours
15)Cooling system	Japanese semiconductor + water +wind +cooling gel
16)Electrical Requirements	100/110V, 50-60HZ or 230260V, 50-60HZ
17)Dimension:	59cm*66cm*125cm(L*W*H)
18)Net Weight	56kgs

IPL Instruction



When IPL irradiates the skin, light energy with particular wavelength will be selectively absorbed by melanin

of hair follicles .When the heated temperature of follicles reaches high enough their structures will be

damaged irreversibly, finally to achieve the effect of removing the unwanted hair.



I Theory:

E-Photon technology is a combination of the advanced technologies:
1)IPL (Intense Pulsed Light )
2)RF (Bipolar Radio Frequency)



II Application:

1) Hair Removal /Photo  epilation (reduction of unwanted hairs).
2) Photorejuvenation, for fine wrinkle, large pores, solar pigmentation.
3) Benign Brown Pigmentation, such as freckles, post traumatic hyperpigmentation, melasma.
4) Dilated Vessels, such as varicose veins (vascular), telangiectasis, port wine stains,hemangiomas, rosacea.
5) Poikiloderma
6) Scars and Stains
7) Acne Vulgaris



Accessories



Before & After Treatment -Use Our Device





Packaging & Shipping

Packaging:Standard Export Aluminum Alloy

How does it works?



IPL treatment is effective based on its selective absorbability. When the intense pulsed light penetrates the epidermis, the energy of light will be greatly absorbed by the pigments in epidermis. High energy and dark color skin will be with high risk in treatment. Moreover, majority of the heat is reflected andrefracted at the same time, only 30% to 40% of energy is utilizable. Therefore, it needs to increase the energy for a better treatment result. However, majority heat is absorbed by the pigments inepidermis, which directly block to use high energy for treatment, so that affects the single treatment result.



Shipping: Express, door to door service / Air Cargo Shipping / Seas Shipping



Our Services

Sample Service:



OEM Service: Acording to buy 's requirement to do everything.(Likes design operation system,

                       put logo on the machine(etc) for buyer. MOQ 10 sets.



Warranty Service: One Year warranty
                               Life long technical support
                               Various traing



Company Information

Certification

Exhibition



Business Show



FAQ



Thanks for your visiting !

If any question please contact us directly by   Email or

                                                                 Skype : carey.har

                                                                 Mobile: 0086 13717619664

Thanks for your inquiry !!!





The principle of IPL

Applying the technique of IPL and Bipolar Radio Frequency,the equipment acts on the entire skin corium and connective tissue,stimulates the collagen of different depth to realing and grow,the gets treatment effect.Biopolar RF release energy at the same time,with the selective absorbtion for the skin to light energy,various pathological tissues of corium and epidermis creates photothermolysis effect.Since light energy is far below conventional IPL,the pigment tissue and vascular pathological tissue of the corium and epidermis would absorb more energy without injuring the epidermis,and then remove these pathological tissue better and get the effect.
