Permanent laser hair removal light hair

Technical parameter :

Light Source	Intense Pulsed Light
Wave Length	690-1200 nm,560-1200 nm,430—1200nm
Light guide	Crystal light guide
Control Mode	Touch Control
Safety Classification	Class I, Type B
E-light RF	5Mhz
Energy density	10-60J/cm2  (Deviation≤±2%)
Pulse duration/width	1-30ms
Frequency	≤1P/3S
Spot size	16×50mm (HR) 8×34mm(SR/VR) ( Deviation≤0.2mm)
Spot Surface Temperature	0-5 Degrees Celsius
Cooling system	Semiconductor Refrigeration +Water Cooling +Wind Cooling
Size	length Width Height 470×360×1040mm
Weight (net weight)	40kg
Fuse Specification	Ø5×2510A
Input Power	1800W
Power requirement	AC220V,AC110V



Handlepiece:

1. Specific wavelength handlepiece ,no use filter , more accurate energy output , more durable and more professional .



2 Durable&powerful Xenon lamp

NBW-I323 adopts UK Xenon tube, which ensures its long lifespan . Each flash contain 1~10 pulse adjustable .

Warranty 30000 flash /300000 pulse for each handle .Max 60000 flash/600000 pulse .

Customize xenon lamp available if you give the 3 parameter above .



3. Double power supply

Exposed big capacitance may cause serious danger because it reserve the energy even the machine closed . We use enclosed capacitance ensure the powerful energy supply also in case of the risk .



4.Cooling

Too much heat will stop the IPL machine working

Semiconductor + water + wind top level cooling system continues using more then 24 hours .



Semiconductor : Use double-deck thermoelectric cooler, providing -4°C protects epidermis while hair follicle is acted Unlike conventional single cooler

Water cooling : 60m high pressure vane pump + 10L big water tank , Better and stable water circulation rather then magnitic .

Wind cooling: 4 DC 12v power fan with copper condensor 4 times better cooling then aluminum



5. Humanized easy work system

Water flow , working temperature real-time auto detection and safe working alert  .

16*50 and 8*34 big spot size , don't suffer the long times treatment any more .

Easy operate , choose handle , adjust energy , start work

Shot time record on screen , when shots use up , consumble new handles easy change here.



Applications:

Nubway IPL NBW-I323, suitable for the performance of Spa, skin Care Center, Clinic, Medical Spa and IPL (Intense Pulse Light is a kind of high strength, broad spectrum and non-succession light, multifunction for

Hair removal ; Acne clearance ;Skin rejuvenation ; Pigmentation and vascular veins problem .

Technical HR SR VR handlepiece

Handpiece	Wavelength	Function
HR	690-1200nm	For hair removal
SR	560-1200nm	Remove pigmented lesions; freckles; age spots; sunburn spots; reduce wrinkles; shrink pores; rejuvenate skin and enhance skin elasticity
VR	420-1200nm	Remove vascular lesions on face and bottlenose;Lighten and remove acne



Other popular wavelength 950nm,940nm,690nm,640nm,570nm,etc .All available .

RF E-light 5Mhz .

Real CE approved , quality based machine ,safe , durable and effective .

1.2 years warranty, if there any problem happens with your machine, we will repair

it free of charge (except the intended damage)

2.Free training, user manual and operation video are available, also, if it is not

enough, we can provide the online face to face education

3.OEM/ODM services, your logo, outshape, language, interface can specially be

designed on your machine

1.  What is IPL?
Intense Pulsed Light is a technology where light is converted into heat energy.
Treatments are like a very powerful camera flash lamp being held against your skin.
The selected light waves target chromophores (colour pigments) such as melanin in brown spots and freckles; and such as haemoglobin in broken or diffused blood vessels.  The light waves can also target specific protein molecules in acne bacteria and in collagen.  IPL treats all conditions without disruption to the skin’s surface.
.

2.  What is the difference between IPL and Laser?
Lasers have been used in surgery for years.  The IPL is an adaptation of the laser, more suited to the beauty industry.  The biggest difference between laser and IPL, as far as treatment is concerned, is the coverage.   The laser beam is very narrow, only covering a small spot at a time, while IPL coverage is several times the area, and therefore treatments are much quicker.  The surface area of the nubway IPL applicator head is 8 square cm – one of the largest on the market.

Lasers produce light from one specific wavelength, or colour, for a very specific target.  The light emitted from the IPL is composed of a spectrum of colours from different wavelengths, enabling selective photo-absorption (light absorption) to different targets.  In other words, using the IPL is like using a group of lasers in a single treatment.
.

3.  Permanent Hair Reduction: How does it work?
Intense Pulsed Light targets the colour pigment (melanin) in the hairs. Therefore white hairs can not be treated. Dark hairs on fair skin have the best and quickest results. Fair hairs will require extra treatments with lesser results. Caution is required when treating hairs on darker skins; this is explained below and would be discussed more fully during your consultation.
The hair growth cycle:
Hairs grow in constant cycles:  Firstly hairs are actively growing, then they become dormant (resting), and finally they loosen and shed, only to be replaced by more new, actively growing hairs.
Only hair follicles in the active growth stage are disabled by IPL treatments.
Hairs in the dormant stage of the growth cycle normally remain anchored in the follicles for weeks or months, depending on their location, but their follicles and associated hair germination cells are not disabled by IPL treatments.  These follicles will be treated in subsequent sessions.   This is why you need repeated sessions.  Hair growth becomes sparser with each session.   All treated hairs should shed within about two weeks.
.

4.  Skin Rejuvenation: How does it work?
–  Skin Tone and Re-texture
–  Pigmentation
–  Vascular Lesions
–  Acne & Rosacea

Skin Rejuvenation is also known as photo-rejuvenation – the non-invasive, non surgical face lift.
The Intense Pulsed Light is absorbed by colour particles which are present in blood and in melanin.
The IPL also treats the propioni-bacterium in acne and protein present in cells which produce collagen.

Pigmentation marks slowly come to the skin’s surface and are shed naturally.
Vascular lesions dissipate into the lymphatic system for excretion, just as bruises do.
Enlarged pores, minor pitting and scarring diminish and fade.
Fine lines and wrinkles are softened and may virtually disappear.
Collagen & elastin production increases.

.

5.  How often will customer need treatments?

a. PERMANENT HAIR REDUCTION
A course of 5 to 10 treatments is usually required to treat hairs at all stages of the hair growth cycle, at 3 to 6 week intervals; which varies depending on hair type and colour, and the location being treated. Fair hairs will require extra treatments. White hairs can not be treated.

A maintenance session may be necessary from time to time, due to the development of new hair growth appearing, as our hormonal balance continues to change with age, or due to the influence of stress, illness, disease and drugs i.e; steroids or contraceptive pills.

b. SKIN REJUVENATION:
It is difficult to predict the number of sessions required, as it depends on the nature of the lesions to be treated and their size, plus the client’s skin type, condition and colour.  Some conditions may require maintenance treatments from time to time.  This will be discussed during your consultation.  Different types of skin rejuvenation require different numbers of treatments.

The following is a guide only:
SKIN TONE & RE-TEXTURE:
Fine lines & wrinkles, enlarged pores, minor pitting & scarring,etc
2 to 4 treatments usually recommended, at 4 to 6 week intervals.

VASCULAR LESIONS:
Facial redness, broken capillaries, spider veins, etc
2 to 6 treatments usually recommended, at 2 to 6 week intervals.

PIGMENTATION MARKS:
Freckles, sun spots, flat birthmarks, etc,
2 to 8 treatments usually recommended, at 4 to 6 week intervals.

ROSACEA AND ACNE:
Results are profound, but these hormonal conditions may return.
2 to 6 treatments usually recommended, at 1 to 3 week intervals.

6.  Is it painful?
Some treatments have little or no sensation at all, but for other treatments, clients may feel a slight sting, similar to the flick of a rubber band against your skin.  It is certainly not unbearable, and we can always reduce the intensity if you feel the need.  Immediately after some treatments you may feel a mild heat for a few minutes, or a couple of hours, but after most treatments you will feel next to nothing at all.
.

7.  How will I look after the treatment?
In most cases there is no visible reaction and you would be expected to be able to return to work and resume your normal activities immediately after your appointment.  However, IPL causes heat in the target tissues; therefore it is quite acceptable for the area to be slightly reddened immediately after treatment, but this  would normally dissipate within half an hour.  It is possible for the skin to appear slightly red for a couple of hours and up to 24 hours.   If a reaction is visible after 48 hours it is imperative to contact your IPL operator for further advice.

8.  Can Dark Skins Be Treated?

Light produced by laser and by IPL is absorbed by the colour pigment, melanin, which is present in our hair and skin.  Caution is required when treating people with dark skins, Asian skins and some other skins which tan very easily.  Hyper-pigmentation or blanching of the skin is likely to occur if there is too much melanin present in the skin.  It is possible to treat medium to medium/dark skins on a low intensity.  The consultation process and a test patch, will determine whether each individual can be treated.  Strict guidelines must be adhered to, when treating darker skinned people, using only low levels of intensity at each session, and therefore more treatments will be needed to achieve a result.  Skins such as Negroid, Melanesian and some darker Indian skins are not treatable – for both skin rejuvenation and for hair removal.  Electrolysis is an option for these people, but it too, must be administered with caution, on a low intensity, due to the possiblility of hyperpigmentation or blanching.

9.  Important After Care:

For 24 hours after each IPL treatment:

• No sun exposure or UV exposure of sun beds
• Wear sun block with both UVA and UVB protection
• No depilatory,  AHA, glycolic or salicylic creams
• No very hot baths or showers – tepid water only
• No heat treatments e.g. sauna
• No swimming in chlorinated pools or spa baths
• No deodorant – if underarms treated
• No perfumes, highly perfumed soaps or lotions, etc.

Long term After Care:

• Always wear a good sun block with both UVA and UVB protection
• Avoid excessive sun or UV exposure.  Cover up and be sun-safe

Beijing Nubway S&T Co,Ltd is a factory for Laser and Light based beauty aesthetic equipment. Main product included IPL SHR,Cryolipolysis slimming,diode Laser hair removal,spider vein/vascular removal,CO2 laser,nd yag laser tattoo removal,HIFUSHAPE focused untrasound slimming machine,etc.

We have our own research and development department and our own factory so we can provide OEM and ODM service for the distributors all over the world. In beauty equipment industry, our factory is one of the biggest in China, it includes several production lines, Material Library, shipping department, Inspection Area.

We highly control the manufacturing process and quality assurance .
