The principle of IPL
Applying the technique of IPL and Bipolar Radio Frequency,the equipment acts on the entire skin corium and connective tissue,stimulates the collagen of different depth to realing and grow,the gets treatment effect.Biopolar RF release energy at the same time,with the selective absorbtion for the skin to light energy,various pathological tissues of corium and epidermis creates photothermolysis effect.Since light energy is far below conventional IPL,the pigment tissue and vascular pathological tissue of the corium and epidermis would absorb more energy without injuring the epidermis,and then remove these pathological tissue better and get the effect.
ipl system equipment advanced e-light ipl/rf with big spot
Model No.: MED-210
Working Principle:
IPL (Intense Pulsed Light ) is a non-invasive skin treatment that emits powerful bursts of light energy to treat unwanted hair, sun damaged skin, and wrinkles, etc. without damaging the surface of your skin. IPL systems use flash lamps to emit micro pulses of light across a broad band of visible wavelengths. By using gentle pulses of light momentarily to create heat, IPL can permanently disable hair follicles, preventing future growth. The melanin in the hair (which gives it its colour) absorbs the light, which is then converted into heat. This heat is transferred to the growth cells surrounding the root of the hair, disabling them.
Similarly, IPL also achieves excellent long term results when treating thread veins, skin pigmentation, acne and other skin complaints.
Applications:
1) 750-1200nm: Hair Removal (Skin Type IV)
2) 690-1200nm: Hair Removal (Skin Type III)
3) 640-1200nm: Hair Removal (Skin Type I & II ) ; Wrinkle Removal
4) 590-1200nm: Pigmentation and Vascularity; Skin Rejuvenation
5) 560-1200nm: Vascular and Pigmented Lesions; Skin Rejuvenation
6) 530-1200nm: Skin Rejuvenation; Superficial Vascular Lesions
7) 510-1200nm: Superficial Vascular Lesions
8) 480-1200nm: Light Pigmentation
9) 430-1200nm: Acne
Advantages:
1) Butterfly design= Hot Sales!
2) Intelligent+ professional operation=parameters setting automatically
3) Lamps for promotion (30,000-100,000shots for option)
4) 12000UF capacitor big power,ensure stable output energy
Applications:
Skin rejuvenation: pores refining, improve rough, dark and gloomy skin, restore skin elasticity
Pigment treatment: freckles, sun-burn spots, senile plaque, pigmentation spots
Hair removal: armpit, chest, lip, arms, legs, beard, bikini etc.
Vascular, spider angioma, acne rosacea
Acne: pimples, improve seborrheic oily skin and acne scars
5) Magnetic drive pump controlled water circulation: lower noise, longer lifetime
Technical Specifications:
Wavelength (Spectrum) |
640-1200nm(HR) |
Energy Density (Fluence) |
10-60J/cm2 |
Spot Size |
15x50mm2 (HR) |
Pulse Repetition Rate |
0.2Hz; 2Hz |
Pulse Duration |
0.5-15ms
When IPL irradiates the skin, light energy with particular wavelength will be selectively absorbed by melanin of hair follicles .When the heated temperature of follicles reaches high enough their structures will be damaged irreversibly, finally to achieve the effect of removing the unwanted hair. |
Pulse Delay |
1-50ms |
Pulses |
1-15 pulses |
IPL Peak Power |
1400W |
Cooling |
Continuous Crystal contact cooling (-4°C~4°C ) + Air cooling + Closed water circulation cooling |
Stand-by Working |
Continuously for 12 hours |
Display |
8.4" True Color LCD Touch Screen |
Electrical Requirements |
100-240VAC, 20A max., 50/60Hz |
Net Weight |
27 kgs |
Dimensions (WxDxH) |
52*60*37cm |
How does it works?
IPL treatment is effective based on its selective absorbability. When the intense pulsed light penetrates the epidermis, the energy of light will be greatly absorbed by the pigments in epidermis. High energy and dark color skin will be with high risk in treatment. Moreover, majority of the heat is reflected andrefracted at the same time, only 30% to 40% of energy is utilizable. Therefore, it needs to increase the energy for a better treatment result. However, majority heat is absorbed by the pigments inepidermis, which directly block to use high energy for treatment, so that affects the single treatment result.
