UHF TV Antenna

US$ 1,290 - 5,160 MOQ: 1 Piece

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

ZHC

Model Number:

UHF Slot

Hangzhou Zhongchuan Digital Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name ZHC

Model Number UHF Slot

Specifications

1.High-gain design, cirular polarition,
2.TV & DTV compatible,
3.Easy to install, sheltering from rain and snow.

Product Description

UHF TV Antenna

1.Frequency range 470-860MHz.

2.High-gain design 13dBd-18dBd.

3.Circular polarization suitable for high building concentration area coverage.

4.Compatible mobile digital TV application.

5.Omni-directional radiation field, it can be directional radiation according to requirements.

6.Adopting quality electro silvering copper to reduce high-frequency loss.

7.Adopting anti-aging high-strength glass fiber reinforced plastics cover for tight seal and sheltering from rain and snow.

8.To conduct zero point padding and lobe downwardness to achieve the best coverage effect.

9.It occupies little space; flexible installation is suitable for spanning over the top of the tower or the side of the tower.

Product Display :

Technical Specifications:

Electrical Specification		Mechanical Specification
Frequency range	470-860MHz	Size(mm)	φ250x3000x12000
Input impedance	50Ω	Total weight	57Kg(Omni-directional) 79Kg(Directional)
Input interface	IF45/70/110-50K	Wind load	750N(Wind velocity 150Km/h)
Maximum power capacity	1KW/5KW/10KW	Safety factor	2(Wind velocity 225Km/h)
VSWR(Designated frequency)	<1.10	Material	Reflector board: Stainless steel
Polarization ways	Circular polarization		Radiator: Copper
Gain	13-18dB		Inner conductor:Copper (coating silver)
Half power angle	E-map ±7 H-map ±150		Protection cover: FRP
Lightning protection	DC Ground	Installation mode	Independence/hung in side
