Specifications
Customized NdFeB magnets with our advanced processing technology. ROHS and REACH certified.N35SH Big Dimension Ring Magnets
| Grade: | N35SH | Working Temperature: | 150 °C | Material: | NdFeB |
| Shape: | ring | Size: | customized | Coating: | Ni |
| Density(g/cm3): | 7.4-7.6 | Br (Retentivity) | 11.7~12.1KGs (1170~1210 mT) | BHMax | 33~36MGOe (263~287 KJ/m3) |
PS: The parameters are different as per the difference of the grade.
Product Characteristics:
1) Material: Sintered Neodymium-Iron-Boron;
2) Working Temperature: 0 ~ 220 celsius;
3) Grade: N35, N38, N40, N42, N45, N48, N50, N52 ( N, M, H, SH, UH, EH, AH );
4) Shape: ring;
5) Size: customized;
6) Coating: Ni, Zn, gold, copper, epoxy and so on;
7) Dimension Range: Φ 2 ~ Φ 100 mm (i.e. Φ 0.08 ″ ~ Φ 4 ″ ), special dimension please contact for more details;
8) Application: chargers, sensors, motors, rotors, wind turbines, wind generators, loudspeakers, magnetic hooks, magnetic holder, filters automobiles, bag closures and so on;
9) Quality Assurance : ISO 9001:2008, RoHS, Reach Certified;
10) Physical Property of Magnetic Material: High Coercive Force, High density, High remanence, Anti-demagnetizing, Strong corrosion-resistance, Different series, different work temperature.
Sincerely welcome you to visit our factory and cooperate with esteemed OEM!!
11) Product Photo
12) Factory View and Production Equipments
