Help CenterGMP Standard Electric Heating Vacuum Homogenizing Emulsifier
Related Products
-
One Warranty Vacuum Homogenizing Emulsifier for CosmeticUS$ 6,000 - 30,000MOQ: 1 Set -
Automatic Vacuum Homogeneous Emulsifying Mixer for CreamUS$ 6,600 - 45,800MOQ: 1 Set
-
Factory Direct Supply Vacuum Homogeneous Emulsifying MachineUS$ 6,000 - 30,000MOQ: 1 Set
-
2014 Vacuum Homogeneous Emulsifying Mixer for CosmeticUS$ 6,600 - 45,800MOQ: 1 Set
-
Germany Technology Steam Heating Vacuum Homogeneous Emulsifying MachineUS$ 6,000 - 30,000MOQ: 1 Set
Specifications
Vacuum homogenizing emulsifier1.Import Material .
2.Long Working Life.
3.Easy operation .
4.Reasonable price.
GMP standard electric heating vacuum homogenizing emulsifier
The Main Composition:
The vacuum emulsifying mixer is mainly composed of :
1.water pot
2.oil pot
3.emusifing pot
4.vacuum system
5.lifting system
6.electric control system
7.operation platform
Usage And Application Field:
The product is mainly applied in such industries as daily chemical care products ,biopharmaceutical industry ,food industry ,paint and ink .
The emulsifying effect is more prominent for material of high viscosity and high solid content.
Flow Chart Of Vacuum Emulsifying Mixer:
About The Vacuum Emulsifyer machine :
The controlling system adopts electric or steam cotrol system, stable and simple to manage
The triple mixing adopts the imported frequency converter for speed adjustment, which can meet different technological demands.
The homogenizing structure made through German technology adopts the imported double-end mechanical seal dffect. The max emulsifying rotation speed can reach 4200rpm and the highest shearing fineness can reach 0.2-5μm.
The vacuum defoaming can make the materials meet the requirement of being aseptic.
Lifting system, easy to clean, and the main pot can adopt tilt discharge.
Pot body welded by imported 3-layer stainless steel plate.,ank body and pipes adopt mirror polishing, conforming to GMP
The tank body can heat or cool materials .Heating modes include steam heating or electric heating.
Technical Parameter:
| Specification | Working Volume | Heating method | Dimension | Weight |
| JT-150 | 150L |
electric heating or steam heating |
2.6X2.4X2M | 650KG |
| JT-250 | 250L | 2.8X2.5X2.2M | 850KG | |
| JT-350 | 350L | 3X2.8X2.3M | 1100KG | |
| JT-500 | 500L | 3.3X3X2.5M | 1500KG | |
| JT-1000 | 1000L | 4.2X3.5X3.8M | 2500KG |
Material sources of parts
Notes: JUTAO Machinery is a professional manufacture of chenemcial machinery and equipment ,accumulating more than 10 years of manufacturing experience since its establishment in 1997. we have been certified to the ISO9001:2000 international quality managment-system.
Notes: We are a professional sales team with high efficiency, and endeavoring to provide satisfactory services to every of our customers as always.
IVORY.LIN (Internationl sales)
Tel: +86 20 29148928
Fax: +86 20 29148928
Mobile: +86 15999964717
