Trapezium Aluminum Housed Wirewound(TRX) 50 Ohm Power Resistor

Name: Trapezium Aluminum Housed Wirewound(TRX) 50 Ohm Power Resistor
Brand: Pak Heng
SKU: 135029925
Availability: InStock

Shenzhen Pak Heng Electronics Co., Ltd.

5Yrs

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Pak Heng

Model Number:

TRX,aluminum housed resistors

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen Hong Kong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Pak Heng

Model Number TRX,aluminum housed resistors

Type Fixed Resistor

Technology Wirewound

Package Type Throught Hole

Resistance 0.5ohm to 35k ohm

Rated Power 40w to 1800w

Temperature Coefficient 300ppm

Operating Temperature -55 to 275'C

Trapezium Aluminum housed wirewound(TRX) 50 ohm power resistor

1,Aluminum crust surface with good performance in heat radiation, suitable for cooling plate installation, can be used in the atrocious environment.

2,Small size, high power load.

3,High insulating capacity, encapsulation by non-flame inorganic Material, good performance in vibration

4,Multi connection form will be easily to fix.

5,Widely used in power supply, transducer, elevator, arena audio and high requirement equipment industry.

6,Resistance tolerance:±1%, ±2% ±5%, ±10%

Power:40W,60W,80W,100W,120W,150W,200W,300W,400W,500W,

600W,800W,1000W

Tolerance: ±1%, ±2% ±5%, ±10%

Range:1R-100K

Description	Power	Tolerance	Range
LRX Gold Aluminum Housed Wire-wound Resistors	5W,10W,25W,30W,50W,75W,100W,150W,200W,300W,500W	±1% ±5% ±10%	1R-100K
TRX Trapezium Aluminum Housed Wire-wound Resistors	40W 60W 80W 100W 120W,150w,200w,300w,400w,500w,600w,800w,1000w	±1% ±5% ±10%	1R-100K
CRX Boat Type Aluminum Housed Wire-wound Resistors	50W 100W 150W	±1% ±5% ±10%	1R-100K
