60kva Ups

Guangzhou Helizhanchuang Electric Technology Co., Ltd.
60kva Ups thumbnail-1
60kva Ups photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
CAP 60kva ups
Model Number:
60kva ups
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
GuangZhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name CAP 60kva ups
Model Number 60kva ups
Phase Three Phase
Protection Other, overcurrent overvoltage short circuit unbalanced loads
Weight 547kg
Output Voltage 380v
Type Other, On-line, 60kva ups
Application Security / Monitoring / Alarm

Specifications

60kva ups
1.with four -steps AVR
2.can drive AC,refrigerator,with RS232,SNMP.

     60Kva Ups





1.It can drive inductive load,airconditioner,refrigerator, TV,fan , also it can drive computer,ATM.



2.with RS232,SNMP.



3.Output pure sine wave



4.Has CE , ISO certificate



tection against short-circuit, overload



6.when the mains come, it willl start the unit automatically.



7. completely controlled by CPU, LCD automatic page turning    display



tection against output short-circuit; Against overload, and when you throw off its load, it will turn on the unit automatically.



9.Can take pump or lift, and other industrial use





ModelSS10SS15SS20SS30SS40SS60SS80SSSSSSSS
100120160200
Rated capacity10KVA15KVA20KVA30KVA40KVA60KVA80KVA100120160200
KVAKVAKVAKVA
Operating principlePure sine wave dual conversion on-line
 PhaseThree phase+N+G
 Voltage380V±25%
AC inputFrequency50HZ±10%
DC inputRated DC voltage360Vdc
floating voltage405Vdc
Cut-off voltage315Vdc
charging timecharge to 90% in 8 hours
AC outputPhase Three phase+N+G
Voltage 380Vac±2%( stable load), 380Vac±5%( fluctuant load)
Frequency50Hz±0.5%(On battery)
Power factor0.8
Wave-formSine wave
Total Voltage harmonics distortionLinear load <3%; non-linear load <5%
Output voltage transient characteristicLoad abrupt change From 0 to 100%)
 <20ms
Transient response time
Crest factor03:01
Overload protection>125%,1min;>150%,200ms
 Full load efficiency≥90%
 Transfer time0ms
system specProtection(Overload, over charge and over discharge; phase error, out the range of voltage and frequency, over current, short circiut, over temperature ect. )
 DisplayLCD and LED indicator
 CommunicationRS232 interface and SNMP card(optional)
 Environment temperature-5~40°C
 Relative ambient humidity20~95% (Non-condensing)
 Altitude<1500m,1% rated capacity decrease against rised 100m
 Cooling methodForced air-cooling with temperature control
 Surge protection10/700Us,5KV ;8/20Us,20KA
  IP21
 Safety rate
 Noise(dB)<55dB<65dB
Dimension450*770*1000700*853*16001070*900*16301390*960*1800
(W*D*H)mm
 227270315377475547950100011001650
Weight(Kg)





 60kva ups60kva ups60kva ups



60kva ups
