Help Center12v120ah 200ah Deep Cycle Battery for 8 Years
Related Products
-
Good Quality 12v 50ah Rechargeable BatteryUS$ 50 - 55MOQ: 1 Piece -
CAP Solar AGM Battery 12V 100AH Deep Cycle BatteryUS$ 1.8 - 180MOQ: 1 Piece
-
Solar AGM Battery 12V 150AH With Sealed Construction in ChinaUS$ 1.8 - 180MOQ: 1 Piece
-
Solar AGM Battery 6V 250AH With Sealed ConstructionUS$ 1.8 - 180MOQ: 1 Piece
-
2015 Hot Sale Product!! Solar AGM Battery 3AH-250AH With Sealed ConstructionUS$ 1.8 - 180MOQ: 1 Piece
SPECIFICATIONS | ||||
Nominal Voltage |
12 V |
|||
Rated Capacity (20 hour rate) |
100 AH |
|||
|
Dimensions (Length*Width*Height*Total Height )/mm |
332*174*214 mm |
|||
Weight Approx |
32 kg |
|||
| ||||
CHARACTERIESTICS | ||||
|
Capacity 25°C |
20 Hour rate |
7 AH |
||
10 Hour rate |
6.51 AH |
|||
5 Hour rate |
5.95 AH |
|||
1 Hour rate |
4.2 AH |
|||
|
|
|||
Internal Resistance |
Fully charged battery at 25°C |
25 m Ω |
||
|
Capacity affected by temperature (20 hour rate) |
40°C 25°C 0°C -15°C |
102% 100% 85% 65% |
||
|
Self-Discharge At 25°C |
Capacity after 3 month storage Capacity after 6 month storage Capacity after 12 month storage |
91% 82% 64% |
||
Terminal Type |
T1,T2 |
|||
|
Charge (Constant Voltage) |
Cycle use |
Initial Charging Current less than 2.80 A Voltage 14.5~14.9V |
||
Float use |
Voltage 13.6~13.8V |
|||
12v 100AH lead acid Battery features:
- Maintenance free
- High power to weight ratio
- No memory effect
- Low self discharge
- CE certificate
- Long service life
- High discharge rate
- Wide operating temperature range
Warnings:
- Matrix series batteries have acid in the case and are fully charged before leaving factory.
Do not attempt to dismantle the battery, if accidental skin/eye contact is made with electrolyte,
seek medical advice immediately.
- Do not use a new battery with an old one.
- Do not use the battery in sealed container.
- Each battery should have detailed record including the ex-factory date, installing date and using record.
- Check the connection of wire in a fixed interval (once a year). If there is any looseness should tighten the wire.
- Wipe the surface of the battery with soft cloth in a fixed interval (once three months) and always keep the battery clean.
- Avoid using any kind of organic solvents for cleaning the surface of the battery.
Applications
- Fire protection and security uninterruptible power supply
- Electronic appliance and other backup power supply
- Telephone and telecommunication equipment
- Uninterruptible power supply systems for bank
- Emergency lighting or small lamp fitting
- Electric power system
- Security system
