10.2inch TFT LCd Monitor Restaurant USB SD CF External Push Button Panel Display LCD TV with Memory Card Slot Advertising Player

FOB Price

USD $60 - $100 / Piece

50 Pieces(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port NINGBO PORT
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Zhejiang, China	Brand Name:	OEM ODM	Model Number:	PT102D-6A external button
Type:	TFT	Application:	Indoor	Panel Size:	10.2inch
Max Resolution:	800*3(RGB)(W) X 480(H)	Viewing Angle:	45(Right)/45(Left)/15(Top)/35(Bottom)	Pixel Pitch:	0.0925*0.276
Color:	262k(RGB 6 bit)	Contrast Ratio:	500:1	Brightness:	250cb/m
Response Time:	10msec	Input Voltage:	AC 110V~240V, ≤12W

Product Description

10.2inch TFT LCd Monitor Restaurant USB SD CF External Push Button Panel Display LCD TV with Memory Card Slot Advertising Player

Model: PT102D-6A

Item: 10.2inch lcd advertising player

1. Various appearances at your choice.
2. Size can customized according to you.

Auto loop play the first file when power on. Press the button, it willl turn to play the second file. When the second file is finished, it will return to loop play the first file.
Push button: various functions can be customized according to clients' requirements.
Auto-play when turned on with the MMC/SD/CF/USB inserted
Support BGM mode (photo and music synchronized play)
Pictures can be rotated 90°( Vertical display)
Super time switch function, can auto turn on/off at a specific time
Slideshow time can be set up by yourself
It can show the clock
Full function remote control, easy operation
Multi-Language OSD: Chinese, English, Japanese, French, German, Danish, Spanish

Display	LCD size	10.2inch (Diagonal)
	Resolution	800*3(RGB)(W) x 480(H) (digital panel)
	Luminance	250cd/m²
	Contrast Ratio	300:1
	Viewing Angle	+70/-70 (H), +50/-70(V) (degree)
	Backlight	LED back light
	Display Mode Optional	16:9 / 4:3
I/O	AC Power Input	AC: 100~240 V
	DC Power Output	12V / 1.5A
	Integrated Speakers	2W x 2
Supported Card & Format	Interface	CF/MMC/SD/USB(2.0)
	Photo	JPEG, BMP
	Video	MPEG 1, MPEG 2, MPEG 4, AVI, MP4, VOB
	Audio	MP3, WMA
Other	Dimensions (LWH)	258 x 171 x 28.5mm non-include bracket
	Shell Color	Default color: pearl white; optional color: blue, black...etc
	Accessories	Bracket(optional), remote control, user manual, AC adapter
	Operating temperature	0°C~ 40°C (32°F~104°F)
Packing	Package	10 PCS/CTN
	Packaging Size	32×28×13 cm (small white box)
	Carton Size	59×57×28 cm (carton)
	Gross Weight	1.5 kgs/pc; 15.5kgs/ctn (not include weight of buttons)
