15.6 inch HD Android Smart Network LCD TV Screen for Bus USB SD TF Wall Mounted LED Advertising monitor
Model: PT156HD-Network
Item: 15.6inch HD Android NETWORK Advertising Display
| Platform and configuration: 1. Hardware platform: ARM Cortex-A8 1.5GHZ processor; 2. Software platform: Based on Android2.3, 4.0 or above operating system; 3. Memory: DDR3: 512MB; Built-in FLASH memory: 2GB NAND | ||
| Supports two boot display modes: portrait display and landscape display | ||
| Support many play modes, such as loop, timing,inter-cut and so on. | ||
| Multi-Language OSD: Chinese, English, and many other languages | ||
Super time switch function: help save power and expend the service life of player; After setting the switch time , the entire system will automatically start at boot time. And automatically turn off at shutdown time. In the state of turn off, the device does not respond to external operations, and does not output any audio and video signals | ||
Support rolling caption:while displaying the advertising videos, the preset text message are displayed at the bottom of the screen. | ||
Clock display: built-in clock IC, can automatically update the time from network and correct system time | ||
| Weather Forecast : Automatically update real-time weather information from network | ||
Split screen display: Support split-screen function of 1080P video, pictures, subtitles, clock, weather forcast, web / Flash and other elements freely | ||
B/S architecture, strong support of background server management software , set ad player parameter online, create and issue playlists online, download server advertising sources in real time / timing, the advertising sources will autoplay after download completed. | ||
| The above same functions can also be applied to 21.5"-46" ad players | ||
| Our professional R&D team can customize personalized products for you. |
| 15.6inch display | LCD size | 15.6″ |
| Resolution | 1366*R.G.B.*768 | |
| Display Size | 344.232(H)*193.536(V) | |
| Pixel Pitch | 0.252(H)*0.252(V) | |
| Luminance | 250cd/m² | |
| Contrast Ratio | 500:1 | |
| Viewing Angle | 160° (CR>5) | |
| Respond Time | 8 ms | |
| HARDWARE INDEX | CPU | Dominant frequency 1.0 - 1.5GHz |
| RAM | 512MB(Optional) | |
| ROM | NAND FLASH 1G(Optional 4G) | |
| Pixel Format | Upto 1080P | |
| System | Android 4.0.3 | |
| Play Mode | REPEAT,TIMING,INSERT PALY and so on | |
| Network | ETHERNET,WiFi,and Other Wireless Device extended | |
| Video Support | wmv,avi,flv,rm,rmvb,mpeg ,ts,mp4 | |
| Photo Support | BMP,JPEG,PNG,GIF | |
| USB2.0 port | USB HOST x 2 | |
| Ethernet | 10M/100M | |
| SD Card | SD/MMC | |
| SATA port | SUPPORT SATA HDD | |
| LVDS | DUAL 8 bit LVDS | |
| HDMI OUT | SUPPORT 1080P OUTPUT | |
| CVBS INPUT | SUPPORT CVBS VIDEO INPUT | |
| AUDIO OUT | LEFT RIGHT AUDIO OUTPUT, DAUL CHANNEL 4R/6W,8R/3W AMPLIFIER | |
| RTC | SUPPORT | |
| TIMER SWITCH | SUPPORT | |
| SYSTEM UPGRADE | SUPPORT USB AND NETWORK UPGRADE | |
| I/O | Adapter | Input: AC 100~240 V 50/60Hz Output: DC 12V, 2A |
| Other | Material | Metal shell, plexiglass panel |
| Accessories | Adapter | |
| Operating temperature | 0°C~ 40°C (32℉~104℉) |
