Switched Ac Adapter Power Supply 12V 1A
US$ 10 - 20
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GVE
Model Number:
GM12W
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Hong Kong Guangzhou China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
17-Year Manufacturer Gve Smps Constact Voltage Power Supply 12V DcUS$ 10 - 20MOQ: 100 Pieces -
Switching Mode 12V Dc Battery Backup Power SupplyUS$ 10 - 20MOQ: 100 Pieces
-
Ac To Dc Single Output 12 Volt 5 Amp 60 Watt S-60-12 Power SupplyUS$ 10 - 20MOQ: 100 Pieces
-
12V 20A Dc 250W Led Driver Power Supply S-250-12US$ 10 - 20MOQ: 100 Pieces
-
12V 48V 50A Dc Switching Industrial Power SupplyUS$ 10 - 20MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
GVE
Model Number
GM12W
Output Type
DC
Connection
Plug In
GVE brand UL/ CUL/ FCC/ CCC/ CB/ GS/ CE/ TUV/ PSE/ KETI/ RoHS certified power adapter
Product Details
Features
- Universal AC input / Full range
- No load power consumption < 0.3W
- Comply with CCC, CE, UL, CUL, GS, RoHS, FCC, GS, CB, TUV, SAA, KC, PSE standards
- Protections: Short circuit / Overload / Over voltage
- 3 year warranty
- Repare rate per year <0.08%
- Pass LPS
- 100% full load burn-in test
- Fully enclosed plastic case
- LED indicator for power on
Applications
- Consumer electronic devices
- Telecommunications devices
- Industrial equipment
Models options
| Model | Max Power | Output Voltage | Output Current | Efficiency | Size |
| GM10W | 10W |
3~48V (ex:5/6/7.5/9/12/ 15/16/19/24/48V) |
0.1~2.5A | 73% | 74*36*28mm |
| GM12W | 12W | 0.1~2.5A | 78*29*42mm | ||
| GM18W | 18W | 0.1~2.5A | 78*45*32mm | ||
| GM26W | 26W | 0.1~3A | 78*45*32mm | ||
| GM36W | 36W | 0.1~4A | 87.5*49*32mm |
*** Contact us for Custom Services ***
Optional Plugs
Detailed datas
| Specification | |||
| Input Voltage | 100~240VAC | Input Frequency | 50~60Hz |
| Input Current | 0.5A max at low line input and DC output full load | ||
| Output Voltage | 3~48V | Output Current | 0.1~16A |
| Efficiency |
73% Min. At 100vac input and output Max.Load 73% Min. At 240vac input and output Max.Load |
||
| Overshoot | 15% Max.When power supply at turn on or turn off | ||
| Operating Temperature | 0°C~40°C |
Storage Temperature |
-20°C~85°C |
| Electrical Data | |||
| Dieletric Withstand | 4000VAC primary~secondary | Leakage Current | 0.25mA @2 pin / 0.35mA @3 pin |
| Efficiency | Energy star level V & ERP stage 2 certified | EMI Conduction & Radiation | Complied to EN55022 Class B |
| Harmonic Current | Complied to EN61000-3-2 | MTBF | 50000 calculated hours at 25°C by Telcordia SR-332 |
Why Choose Us
Since 1999, GVE has been providing top quality 18~250W AC/DC Desktop / Wall-Mounted Power Adaptors, Industrial Switch-Mode Power Supplies, Li-po Battery Chargers, etc. Now GVE has become one of China's most trustworthy brands. Our 18 series (over 1000 models) power supply products have been widely applied in automation, communication, LED lighting, medical, office automation, household application fields.
Certified Products
- Top product quality is the principle that GVE has been stick to.
- Our products are certified by various standards and organisatons include:
Repaire Rate Less Than 0.08%
- With 16-year experience, GVE has developed a high-tech, rigid quality-controling production line.
- We've set up our own EMC lab and EMC parameter is checked for each load of products.
- Every single product is individually tested and 100% full-load burn-in test passed before being put on sale.
Customization Capabilities
- Our R&D team is equiped with 15 engineers, and they have an average industry experience of 22 years
- Your ideas will be fully understood and delivered by our well-trained sales experts
- Samples will be promptly provided for your review and approval
Cooperating with Famous Companies
- With good products and business reputation, GVE has won the trust of various famous companies
- We've established long term partnetship with the following companies :
Packing and Shipping
Detailed Packing
- PE bags + clapboards + outer cartons
- Custom packing service available
Shipping Details
- Small orders will be delivered by DHL, FEDEX, UPS, TNT or other international express. Normally it takes 3-7 days to deliver to your desination
- Shippment will be arranged under FOB condition
FAQ
FAQ
Q : Can I get any samples ?
A : Yes, we offer free samples (1 or 2 pcs), but delivery fee will be on your charge.
Q : What is your payment terms ?
A : T/T or cash. We accept T/T 30% downpayment and 70% balance before shipment
Contact US
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2004
Factory Size
10,000-30,000 square meters
Total Employees
501 - 1000 People
