Help CenterPE Heat-Shrinkable Stress Control Tube for Cable Joint XLPE Cable
Related Products
-
10 ~ 35kV Cold Shrink Cable JointUS$ 15 - 350MOQ: 50 Sets -
LDPE PE Heat Shrinkable Straight Through 3-core Cable Joint up to 36kv for XLPE CableUS$ 5 - 200MOQ: 50 Sets
-
Poly PE Heat Shrinkable Indoor Termination up to 36kv for XLPE/PILC CableUS$ 5 - 200MOQ: 50 Sets
-
Heat-shrinkable Wraparound Sleeves for Cable RepairUS$ 20 - 50MOQ: 100 Sets
-
RSBJ Reinforcing Wrapround Cable Repair SleevesUS$ 20 - 50MOQ: 100 Sets
Specifications
Stress Control Tube plays an important role in the structure of cable accessories. It contributes to releasing stress
Stress control tube
Applications:
The specially designed chemical formulation and carefully controlled manufacture technology effectively release the high electrical stress present at insulation screen in termination and joint of power cables from 11kV to 24
Performancc of product | ||
Property |
Test Method |
Typical Data |
Physical | ||
Tensile strength |
ASTM D 638 |
13Mpa |
Elongation at break |
ASTM D 638 |
≥280% |
Water absorption |
ISO 62 |
<1%max |
Longitudinal shrinkage |
-- |
<10% |
Eccentricity |
ASTM D 2671 |
<25% |
Electrical | ||
Volume resistance |
IEC 93 |
1010Ω.cm(min) |
Withstand voltage |
IEC 250 |
>20KV/mm |
Dielectric constant |
IEC 250 |
12(min) |
Cat No. |
Size |
As |
After Recovery |
Standard |
|
Supplied |
(mm) |
length |
|||
(mm) |
(mm) |
||||
D* (Min.) |
d*(Max.) |
w*(Min.) |
|||
320801 |
HSC-100 16/8 |
16 |
8 |
1.4 |
30m/spool |
320802 |
HSC-100 20/10 |
20 |
10 |
1.4 |
30m/spool |
320803 |
HSC-100 30/12 |
30 |
12 |
1.95 |
30m/spool |
320804 |
HSC-100 35/15 |
35 |
15 |
2.3 |
30m/spool |
320805 |
HSC-100 47/18 |
47 |
18 |
2.4 |
30m/spool |
320806 |
HSC-100 55/20 |
55 |
21 |
2.4 |
30m/spool |
320807 |
HSC-100 54/24 |
54 |
24 |
2.4 |
30m/spool |
320808 |
HSC-100 65/30 |
65 |
30 |
2.4 |
30m/spool |
320809 |
HSC-100 38/14 |
38 |
14 |
2.4 |
1.0-1.5m |
320810 |
HSC-100 47/18 |
47 |
18 |
2.4 |
1.0-1.5m |
320811 |
HSC-100 55/21 |
55 |
21 |
2.4 |
1.0-1.5m |
320812 |
HSC-100 65/25 |
65 |
25 |
2.4 |
1.0-1.5m |
320813 |
HSC-100 75/30 |
75 |
30 |
2.4 |
1.0-1.5m |
