Scotch tape slitting machine/high grade equipement for adhesive tape slitting cutting machine
- 20 Set / Sets per Month
- Qingdao or as buyer's request
- T/T L/C D/P D/A Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | Ruikang | Model Number: | KR-60DFQ-I |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Application:
Use for Machining cutting the Anti-sticking paper and the Dressing Thin Film Materials (such as non-woven fabrics, release paper, BOPP film, CPP film materials).
Features:
1.Material recovery device adopts air expanding shaft.
2.Using magnetic powder clutch control and drive device so as to balance the tension of materials,releasing material using automatically correcting misalignment of the optical tracking device, convenient operation, performance stability (with automatic magnetic powder constant up force control system) due to equipment design constant innovation, the provision of information is only for reference; if changes without notice.
|
Main Technical Parameters:
Effective Width | 600mm/ |
Cutting speed | 0-70m/min |
Unwinding Diameter | 700mm |
Winding Diameter | 350mm |
Corrective Device | Synchronous motor photoelectric eye tracking |
Corrective Power | 1KW |
Host Power | 3kw/3kw/4kw |
Total Power | 4kw/4kw/5kw |
Machine Dimension | 1300*1250*1400mn |
Machine Weight | 500kg/ |
