Help CenterCarbon Graphite Bush Bearing
Related Products
Specifications
graphite bush bearing1. ISO9001-2000
2.wear durable and long life
3.resined materials
4.high density and hardness, high
graphite bush bearing :
Style |
Axis Dia |
Hole dia of pump shell |
Working height |
H1 |
H1 |
C12A21 |
12 |
30 |
7.6 |
7.6 |
17.5 |
C12D20 |
12 |
30 |
9.1 |
6.3 |
17.5 |
C12N20 |
12 |
30 |
7.6 |
7.6 |
17.5 |
C16120 |
15.918 |
38.1 |
9 |
8 |
19.5 |
C17D21 |
17 |
35 |
10.1 |
8 |
20.5 |
1. About our products :
1) Because of using wafer spring, the force acting on the sealing surface is more uniform , the tracking ability performance
of water seal is improved significantly
2) Lower working height. It can improve seal’s working surroundings.
3) Adhesive structure
2. About material Chosen Principals:
Antifreeze Type: Organic acids series, phosphoric acids series, half-organic acids series.
Speed: Max 6000rpm
Mating ring code : M
Silica series : Mating ring code V
Rubber : NBR
3. Water seals assembly:
1) To use the following tools (fixture)while fitting water seal by pressure. In addition, axial runout of the retainer’s big end face must be
within 0.15mm while taking the shaft of bearing as benchmark.
2) The working height of water seal must be within ±0.1mm around the basic working height .
4. Seal operating :
Dry run (dry friction)should be avoided after mounting water seal as possible. This means water seal must be operate in the filled sealing liquid. If dry run is necessary when testing leakage of water seal, speed should be within 200 rpm.
