Wood keyboard, bamboo bluetooth keyboard for iphone/ipad/tablet

Specifications

        Wood keyboard, Bamboo bluetooth keyboard for iphone/ipad/tablet

Name: Wood keyboard

Size:283*126*4MM(L*W*H)

Color:Natural

N/W:295g(±5g)

78 keys

Interface:Bluetooth

Certification:. FCC,CE,RoHs

      Wood keyboard-Products overview:

“Green”concept has implanted in more and more PC products durning the enviromental protection years, stong metal frame with bamboo surface,ecofriendly and firm, simple surface design with bluetooth function,the bluetooth bamboo keyboard also can be connected with both PC and panel computer of iPad or Android .

        Wood keyboard-Technical parameters

Adopt BroadcomMCU,with bluetooth 3.0 interface.

Modulation method:   GFSK 2.4GHZ

Working voltage:      2.5-3.7V

Working current       <1.25mA

Sleeping current         <30μA

Charging current         ≥200mA

Standby time         40 Days

Charging time          2-2.5 Hours

Li-cell volume         250mAh

Charge and discharge     ≥500times.

Working temperature     -40°C-55°C

Humidity               20%-85%

Bamboo bluetooth keyboard-Features:

1.The shell is made of bamboo,plastic and metal,and the connective distance of bluetooth reaches to 33 feet.

2. Light and thin,save space on desk, 24% smaller than the full-scale keyboard. Connect without any line,use the wireless keyboard wherever as you want. 3.Exquisite,lovely and portable.Press convenient for its smart sensitivity,the tenacity of bamboo suit for ergonomic better.

4.Water-proof ,anti-dust,soft feeling ,low noise of key-pressing for its X structure,can be pressed for more than 5 million times.

5.Mature and stable 2.4 G wireless transmission technology,high and stable transmission rate without delaying phenomenon. Low power consumption ,long using time.

6.Bluetooth wireless connection instead of USB interface

7.Built-in rechargeable lithium battery,use for 35 days per charge.

8. Intelligent power saving mode, automatically enter sleep mode without operation for several minutes , the power indicator light goes out, press any key to wake up.

Personality custom-made

Natural bamboo has the feature of plasticity, laser engrave on each face personally and creatively, for example, exclusive company logo, personal zodiac, constellations, patters and so on.It provides unlimited possibilities for your personalization.

Function instructions

1.Open the home page, view the application

2.The main screen brightness increase and decrease

3.Perform all kinds of search, including pictures, music, contacts, etc

4.Browsing the photos

5.Show and hide the screen keyboard

6.The next, play(pause), the one

7.Mute,sound-,sound+

8.Lock/Unlock the screen

9.Power indicator light/code indicator light

Support copy(+C),cut(+X),paste(+V),select all(+A)

Combined with other letters and number keys out special characters

Keep on pressing Fn , F1-F12 and Insert to work.

HOME   Main interface and search files interface switching,

Language switch: Command +Space.

Matching connection steps

1.Make sure the bluetooth connection equipent keeps open

2.Open the power at the bottom of keyboard,  indicator light will light up for 4 seconds, then light off.

3.Press the match-code key, both the bluetooth and power indicator light will be flashing, then the keyboard is ready to connect to the panel computer.

4. Open the connective equipment and search the bluetooth keyboard automaticly.

5.Input right system password by bluetooth keyboard,then press‘Enter’

6. Connect with wireless keyboard,indicator light off,then match code successfully

7. Repeat above steps once fail.

System support

The bluetooth wireless keyboard can be connceted with Iphone ,iPad and iPad Touch, support Windows2000/XP/VISAT/WIN7/ MAC operating system, compatible with othe bluetooth devices.

Charging instructions

Please recharge when the power indicator light twinkles

1.Please connect to keyboard with the USB-B interface.

2.Please connect to PC or power adapter with the USB-A interface.

3.Red indicator light shine when the keyboard is charging ,light off automatically once full, then please take out the USB line.

Energy saving sleep mode:

It will be sleeping mode without operation for 10 minutes ,power indicator light will be off,please press any key to wake up and work again.
