99.95% 3mm Tantalum Wire

99.95% 3mm Tantalum Wire thumbnail-1
99.95% 3mm Tantalum Wire thumbnail-2
99.95% 3mm Tantalum Wire thumbnail-3
99.95% 3mm Tantalum Wire photo-1
99.95% 3mm Tantalum Wire photo-2
99.95% 3mm Tantalum Wire photo-3
US$ 350 - 500 MOQ: 10 Kilograms
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
XLT
Model Number:
XLT-TW01
Contact Supplier Request Quote Chat Now
Baoji Xilitong Non-Ferrous Metal Production Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port Tianjin port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shaanxi, China
Brand Name XLT
Model Number XLT-TW01
Application Industrial
Shape Round
Dimensions Dia:0.1mm-3.0mm


1. Product properties of tantalum wire :

Electrical properties:
LC:≤0.10µA/cm2
Formation liquid: 0.1%H3PO4
Formation temperature: 90±2
Density of the frmation Current: 5mA/cm2
Formation voltage/time: 225V/30min

2.Usage of  tantalum wire:

1. The capacitor grade tantalum wire is mainly used for the production of tantalum electrolytic capacitor anode lead.
2. the medical field: to compensate for muscle tissue, and can be used to suture the nerves and tendons
3. Make a vacuum furnaces heat generating components


3. Specification and tolerance of  tantalum wire :
Spec. diameter tolerance allowed
Specification,mm diameter tolerance allowed,mm
0.10mm~0.15mm ±0.005
>0.15mm~0.30mm ±0.006
>0.30mm ±0.007

4.Mechanical properties of  tantalum wire :
Product condition Tensile strength,MPa Elongation,%
Annealled 300~600 10~30
Half annealled >600~1000 <5
Unannealled >1000 <5

5.Ingredient of  tantalum wire
Model
Element content (mass fraction%)
C
N
O
H
Fe
Si
Ni
Ti
Mo
W
Nb
Ta
Ta1
0.01
0.005
0.015
0.0015
0.005
0.005
0.002
0.002
0.01
0.01
0.05

Ta2
0.02
0.025
0.03
0.005
0.03
0.02
0.005
0.005
0.03
0.04
0.1

TaNb3
0.02
0.025
0.03
0.005
0.03
0.03
0.005
0.005
0.03
0.04
1.5~3.5

TaNb20
0.02
0.025
0.03
0.005
0.03
0.03
0.005
0.005
0.02
0.04
17~23

TaNb40
0.01
0.01
0.02
0.0015
0.01
0.005
0.01
0.01
0.02
0.05
35~42

TaW2.5
0.01
0.01
0.015
0.0015
0.01
0.005
0.01
0.01
0.02
2.0~3.5
0.5

TaW7.5
0.01
0.01
0.015
0.0015
0.01
0.005
0.01
0.01
0.02
6.5~8.5
0.5

TaW10
0.01
0.01
0.015
0.0015
0.01
0.005
0.01
0.01
0.02
9.0~11
0.1








first-classs production equipment





99.95% 3mm tantalum wire







99.95% 3mm tantalum wire









 99.95% 3mm tantalum wire
