1. Light and small, rugged design
IP54: adopts Corning Gorilla Glass, protective level reaches IP54.
6000 times: key connectors has experienced 6000 times’ plug testing.
250g: small figure, easy to carry.
2. Simple design, rich function configuration
Bar code: adopting bar code scanning with high-performance.
GPS: Qualcomm high performance GPS chips, supports A-GPS quick positioning.
RFID: adopts NXP RF NFC chips, supports 13.56 MHz RFID identification.
3. 3G Internet, high speed transmission
WCDMA: supports WCDMA 3G Internet and 14.4 M/s high speed transmission at most.
Wifi: supports IEEE802.11 b/g/n standard.
Bluetooth: supports Bluetooth 4.0 EDR and high speed data transmission.
4. Large touch screen, easy to operate
3.7 inches: 3.7 inches capacitive TP, support 5-point touchness, easy to operate.
178°: IPS hi-lite screen, 178° viewing angel, viewing effect is perfect.
5. Super capacity battery supports working all day
3300mAh: 3300mAh lithium battery, totally meets the needs of working all day.
Physical parameters | |
Dimensions | 162mm H * 69mm W * 25mm D |
Weight | 250g (battery included) |
Operating Temp | -20°C~60° |
Storage Temp | -40°C~80° |
Humidity | 95% RH non-condensing |
Drop Test | 1.2-meter drop protection |
Roller Drop Test | 500 times |
IP Grade | IP54 |
ESD protection | ±8KV contact discharge; ±15KV air discharge |
System Parameters | |
CPU | Qualcomm MSM8225 dual-core 1.2GHz |
OS | Android 4.1 |
RAM/ROM | ROM 4GB eMMC; RAM 512MB DDR2; Support external micro SD card, 32 GB at most |
Display | 3.7 inch capacitive, multi touch; 480*800, IPS display, Corning Gorilla Glass |
Keypad | 5 physical keys (include Android System key, Power key, Scan key, Custom key) |
Battery | lithium polymer battery, 3.7V,3300mAh |
Functional Configuration | |
Bar Codes Scanning | 1D Motorola SE955 (other brand optional), 2D Motorola SE4500 |
Camera | Rear camera 2M FF; 5M AF optional |
NFC | Support ISO14443/ISO15693 standard 13.56MHz RFID identification |
Navigation | Built-in GPS, support AGPS |
Indicator Light | System indicator light; Scanning indicator light |
Audios | Built-in speaker, receiver, microphone, 3.55mm stereo headphone jack, vibrator |
Sensors | Gravity sensor; Ambient light sensor; Proximity sensor |
Network Parameters | |
Network Type | WCDMA/GSM |
Network Spectrum | WCDMA/HSPA 2100/1900/850MHz; |
WLAN | 802.11 b/g/n Built-in Antenna |
Voice/Data Service | Support |
WPAN | BluetoothV4.0+EDR |
External Interface | |
USB Interface | Micro USB2.0, support USB OTG |
Charger Jack | Micro USB2.0, 1A quick charger, optional base |
Power Supply Jack | support 5V/500mA external power supply |
Communication | RS232 |
Development Environment | |
System Environment | Android 4.1/SP-UI |
Development Environment | SP-SDK |
Management Software | SP-PC management suite/MDM |
1. Support google play.
2. Perfect ODM/OEM service.
3. 12 months warranty.
4. SDK support.
