handheld pos terminal with Magnetic IC chip smart card reader /sc card reader

System Parameters of all in one POS

CPU

quad-core 1.2GHz

OS

Android 5.1

RAM/ROM

8GB eMMC/1GB DDR3, supports external 32 GB at most

Display

5.5 inches IPS display, capacitive touch

Keypad

one power physical button, three Touch System Keys(Menu,Back,Home)

Battery

lithium battery, 7.4V, 2000mAh

Functional Configuration of all in one POS

Printer

Built-in 2 inches line thermal printer

Camera

5M AF Rear Camera

Indicator Light

POS indicator light

Audios

Built-in speaker, buzzer, microphone

Magnetic Strip Card

Support 1/2/3 magnetic track, bi-directional swiping, accord with ISO7811, 7812 standard

IC Card

one user slot, support 1.8V/3V/5V card, accord with ISO7816, PBOC and EMV standard

Contactless card

13.56MHz, ISO/IEC 14443 Type A/B, accord with QPBOC standard

SAM Card

one PSAM slot, accord with ISO7816 standard

Password keyboard

Built-in password keyboard

Network Parameters of all in one POS

Network Type

TDD-LTE/FDD-LTE/TD-SCDMA/WCDMA/CDMA/GSM

Network Spectrum

TDD-LTE Band38/Band39/Band40/Band41

FDD-LTE Band1/Band3/Band7
GSM 850/900/1800/1900
WCDMA Band1/Band2/Band5/Band8
TD-SCDMA Band34/Band39
CDMA 800

WLAN

802.11b/g/n Built-in Antenna; standard of security WEP, WPA, WPA-PSK, WPA-v2.0

Voice/Data Service

Support

WPAN

Bluetooth V4.0 + EDR

External Interface of all in one POS

USB Interface

Micro USB2.0

Charger Jack

DC JACK

Power Supply Jack

Pogo Pin, 9.5V--1A

Communication

USB

Development Environment of all in one POS

System Environment

Android 5.1/SP-UI

Development Environment

SP-SDK

Management Software

SP-PC management suite/MDM

Packaging Details:

All in one payment portable pos  machine with NFC reader EMV certificated P2000  Package 1* 2000mAh/7.4V battery 1* USB cable 1* Earphone 1* Power adaptor 1* User Manual 1* Screwdriver

Delivery Detail:

3-5 working days
