Structure and Feature
1.using a large fiat structture,liquid isolution devices ,centrifuge run more smoothly
2.using frequency convercer control ,start a smooth.low energy consumption ,adjustable separation factor .
3.set a feeding tube ,washing pipe ,observation mirrors ,light,reasonable structure,components ,smooth transition to the surface by the polishing treatment an effective removal of a health comers ,external structural components ,fasteners,and drum are made of stainless steel production in line with GMP standard ,
4.Clamshell shell can centrifuge drum shell and mezzanine space for thorough cleansing
5.simple structure ,easy operation and maintenance
6.Airtight structure ,sealing with silicone rubber and fluorine rubber ,can be realized sealed explosion -proof requirements ,suitable for toxic and flammable ,explosive occasions applications
7.Versatility suitable for a wide range
ild die easily broken .
Product drawing
Products are mainly used
P(L)SB-type centrifuge is high performance manual intermittnet operation of the upper discharging centrifuge filtration equipment ,Suitable for viscosity ,hydrophilic strong ,difficult to separator with the fineness of granular or fibrous material suspension to soild ,;iquid separation operation ,not only suitable for small quantities of many varieties of materials separation ,it is suitable for mass production , widely used in pharmaceutical chemical mining,light industry ,food and other areas.For example ,gypsum ammonium ,sulfate Glauber's salt ,iron sulfate ,copper sulfate ,nickel sulfate ,potassium chloride ,sodium acetate ,borax ,soda ,rubber additives ,dye ,plastic raw materials ,soap,grease,all kinds of resin ,salt ,monosodium glutamate ,food additives ,starch,sugar ,vitamins ,antibiotics,herbicides ,copper ,znic and aluminum slag dehydration .
Main technical parameters
| item | model | |||||
| 600 | 800 | 1000 | 1200 | 1250 | 1500 | |
| Drum diameter | 600 | 800 | 1000 | 1200 | 1250 | 1500 |
| Work capacity | 45 | 105 | 160 | 250 | 350 | 500 |
| Speed r/min | 1500 | 1200 | 1100 | 900 | 950 | 700 |
| maxium separation factor | 755 | 640 | 560 | 543 | 631 | 411 |
| packing material limited heavy | 70 | 150 | 220 | 300 | 450 | 700 |
| Motor power | 3 | 7.5 | 11 | 15 | 18.5 | 22 |
| Shape dimension mm | 1300*900*600 | 1720*1270*1300 | 1950*1470*1300 | 2200*1700*1360 | 2300*1800*1500 | 3100*2100*1700 |
| Machine weights | 520 | 1400 | 1800 | 2800 | 3000 | 4880 |
titanium centrifuge for chemical industry
SD series titanium centrifuge is a kind of improved centrifuge base on SS series three feet up discharge centrifuge. It retain the advantage of SS series centrifuge, also reduce labor intensity, quickly discharge, easily clean the filter bag, increase the production efficiency, Avoid contamination and throw of the finished product caused by artificial discharging. SD series centrifuge is fixed for that suspension liquor of high loose, moderate size, difficult to compress, need washing and low viscosity. It is widely used in chemical industry etc.
Structure & principle of titanium centrifuge:
The drum runs with high-speed by motor, materials enter the drum from top feed pipe ,then run forward to the shell of the drum by centrifugal force, in this case liquor pass through the sieve pore and sieve pore of the shell, then be discharged. Then solid be hold in the drum. After the separation open the machine, loosen the lock blocks on lip ring, and suspend the lip ring together with the filter bags containing cake to discharge. Loosen the grip, make sure the filter bag open, then the filter cake will automatic drop down.
Flat sedimenting centrifuge
Certification and Patent
Flat sedimenting centrifuge
Packing and Transportation
Our Company normal order packing is Wooden packing with Avoid stifling Board and Shipping port is Dalian or other Chinese port which all these can be customize by order
decanter centrifuge
Disk centrifuge
tubular centrifuge
Liaoning Fuyi Machinery Co.,Ltd.was established in June 2011 formerly known as Liaoyang Sunny Pharmaceutical Machinery Co.,Ltd.which was Nationl Separation Machinery Standardization Board Member and China General Machinery Industry Association Director . Today the company is the leader in mechanical separation technology in China .
Fuyi is specializing in the production and design of centrifuge , separator and filter equipment which is a high-tech enterprise combine with R&D ,Manufacturing, market prompting and sale.
The company cover more than 60 acres including the advance process plant ,office ,research centre and testing lab .
Fuyi’s president was the first developer and designed of Chinese First Tubular Separator who won many National Reward . The “Tubular Separator” National Standardization , currently in effect is drafted by our company . The company is certified in accordance with ISO9001:2000.
Fuyi Separator provide solution to all technological problems of liquid and solid with more than 30 years experience in centrifugal separation market . For better separation result , every series products is designed and manufactured based on the different liquid material thus customer can achieve perfect separation performance .
Separator and centrifuge made by Fuyi Separator are widely used in the range of areas
Pharmaceutical
Bio-tech and Medicine
Food and Dairy
Chemical
Various Oil
Fuyi Separator promise to provide the most professional technology and advance quality product for global customers.
We made the Standard , we beyond it.
