Home > Products > New Products > 60w centrifugal mini small electric fan
60w centrifugal mini small electric fan
- 100000 Piece / Pieces per Month
- Shanghai/Ningbo
- T/T Credit Card
You May Like
Product Details
Electric Current Type | AC | Blade Material | Cast Iron | |
Mounting | Duct Fan | Place of Origin | Zhejiang, China | |
Brand Name | hangyan | Model Number | CDR2E-100 | |
Power | 60W | Voltage | 220V | |
Air Volume | 350m³/h | Speed | 2650rpm | |
Certification | CCC, CE, Other |
Product Description
CDR 2 E-100 C
1 2 3 4 5
1. CDR-External Rotor Coaxial Duct Fans
2. Number of motor poles: 2-poles,4-quadrupole
3. D:3-phase motors, E:single phase motor
4. The fan then pipe OD: 100-two connected pipe diameter of 100mm
5. Type Code:A-low noise, C-high flow high pressure
◊ Application
CDR Series External Rotor Coaxial Duct Fan is a radial fan.CDR series motor is suitable for long-distance transmission of hotels,clubs,supermarkets,storerooms and restrooms,and places which have noise requirement.
Operating Environment:
Elevation: below 4000m
air humidity: less than 90°C
ambient temperature: -25°C~+60°C for general products
products used in unconventional environment also can be customized.
These fans should fit IP44 grade when being installed in the pipeline system.They cant be used for covering abrasive powder,soot and similar materials.Its shell is made of prefabricated galvanized steel.
◊ Advantage
1. 100% copper wire
2.high efficiency,convenient speed regulation,low price,etc.
3.Compact structure,high capacity and easy installation.
4.CDR fan can resist high pressure and fit long pipeline operation while operation
while operating at low noise.
5 .It has moisture resistance and can be installed in moist environment.
6. small electric fan
Packaging Detail: Cartons 1pcs/ctn
Delivery Detail:depend on order quantity
1.1 year warranty
2.products used in unconventional environment also can be customized.
