hangyan high performance light weight low torque 600w brush 96v electric dc motor
123 |
ZYT |
90 |
- |
600 |
- |
1700 |
1. |
2. |
3. |
|
4. |
|
5. |
1.Body OD:123-fuselage outside diameter of 123mm
2.ZYT:ferrite permanent magnet DC motor
3.Voltage:90-90V.DC input
4.Power:600-rated output power of 600HP
5.Speed:1700-Rated speed 1700rpm
◊ 96v dc motor Drawing
◊ 96v dc motor Specification
What is the detail of our DC MOTOR ?
Material:
Coil:100% copper wire
Commutation:brush
Insulation class:B/F
Protection Class:IP54
Warranty:one year
Feature
1.Ferrite permanent magnet DC motor
2.29 years production experience
3.high efficiency and quantity,convenient speed regulation,Small size, light weight , high power index , low noise, easy speed control,etc
4.Our company can customize permanent magnet DC motor with voltage 12-250v and power of 40-3000w and rotating speed 800-6000rpm revolutions for customers under the condition of without speed reducer
5.The fuselage diameter :82mm 100mm 113mm 123mm 150mm
Operating Environment
Elevation:below 4,000m,
Air humidity:less than 90°C
Ambient temperature: -25°C~+60°C for general products
Products used in unconventional environment also can be customized
Application
1.These motors are widely used for wires, cables, light industry, spinning, paper-making, chemical industry, printing and dyeing, metallurgy, rubber, wire-drawing, extrusion machinery, medical equipment, food processing, printing and packaging and other industries.
2.It can achieve step less speed regulation by constant torque by being equipped with the speed regulator.
3.Besides,our company can customize products when the customer has requirement on batch speed reducer or high temperature and other specific environments.
What is our services ?
1. 100% copper wire
2. 1 year warranty
3. 29 years production experience
4. Compact structure,high capacity and easy installation.
5. It has moisture resistance and can be installed in moist environment.
6. products used in unconventional environment also can be customized.
◊ Company information
Taizhou Hangda Electromechanical Co.,Ltd
1.Founded in 1985, and experienced 20-plus years ups and downs.
2.The company has a team of highly qualified technical staff.
3.The company also carry out technical cooperation with University of Shanghai for Technology and Dalian University Of technology.
4.The products have passed the European CE authentication and the Chinese CCC authentication.
5.The good quality of our products has won the customer's trusting all over the word.
6.We will make great efforts to provide the high quality product and the good service for the customer.
Why choose us?
1. We are a factory focused on fans for more than 25 years.
2, As per your application and requirements, product can be customized to supply .
3, Our sales engineer are here, for your raising question any time.
4, Best production capability, best quality control, best service.
5. Every year 400,000 to 500,000 pieces of external rotor fans were exported to other countries.
◊ Aims:
1. Cooperation aims: Integrity, Fair,Win-win.
2. Service aims: Professionalism, Preciseness, Patience
3. Product aim: High quality, Reasonable price, Customer-oriented.
◊ Missions:
1. We are the bridge between customers & manufacturers.
2. To provide more choices for customers.
3. To help the quality & honest manufacturer to attend products in the world-wide markets and obtain orders.
Hangyan 96v dc motor will keep going,
and hope we will be your best choice!
◊ FAQ
Q1. When can I get the quotation?
We usually quote within 24 hours after we get your inquiry. If you are urgent to get the price, please send the message on trade management or call us directly.
Q2. How can I get a sample to check your quality?
After price confirmed, you can requiry for samples to check quality.
If you need the samples, we will charge for the sample cost. But the sample cost can be refundable when your quantity of first order is above the MOQ
Q3. Can you do OEM for us?
Yes, the product packing can be designed as you want.
Q4. Can I change the voltage and frequency ?
Yes, we can make 220v, 50Hz, 110v, 60Hz, 220v and 110v.
Q5. How about MOQ?
100 pcs for carton box.
Q6. What is your main market?
Eastern Europe, Southeast Asia, South America.
