China Factory Sale High Volume Small Axial Fan for Mining Factories

Taizhou Hangda Electromechanical Co., Ltd.
China Factory Sale High Volume Small Axial Fan for Mining Factories thumbnail-1
China Factory Sale High Volume Small Axial Fan for Mining Factories photo-1
US$ 20 - 150 MOQ: 1 Piece
Key Specifications
Get Latest Price
Electric Current Type:
AC
Mounting:
Free Standing
Blade Material:
Stainless Steel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type AC
Mounting Free Standing
Blade Material Stainless Steel
Place of Origin Zhejiang, China
Brand Name hangyan
Model Number YWF2D-200
Voltage 380V
Power 80W
Air Volume 1080m³/h
Speed 2700RPM
Certification CCC, CE
After-sales Service Provided No overseas service provided



Product Description

Model Description

YWF 2 D -200S -5  L -G

      1        2   3         4      5     6      7     8



1.YWF-External Rotor Axial Fan

2.Motor pole number:2--Two poles 4--Four poles 6--Six poles

3.D-Three-phase motor,E-Single-phase motor

4.Blade diameter:200-blade diameter is 200mm

5.Wnd code:S-induced draft,B-BLOW

6.Blade blade number;5-5 blades

7.Wind leaf shape:L-Faiciform F-SQUARE TYPE,lt-CONTINUUM

8.Fan type:G-pipeline Gaotong,A-short barrel,FA-terms of frame short barrel ,FG-dspests box Gaotong,W-meshenclosure type ,D-fixed type,H-standing type

 China factory sale high volume small axial fan for mining factories

MODEL   NO.

Rated voltage

(V)

Frequency( Hz)

 current

(A)

Input power

(W)

Highest speed

(r/min)

Volume

(m³/h)

Pressure(pa)

  Noise    db(A)

        Capacitor (μF)

  Approx weight

(kg)

YWF2D-200

380

50

0.25

80

2700

1080

122

57

 --

4

YWF2E-200



220





50



0.30

70

2650

1050

120

56

2.5

 3

 China factory sale high volume small axial fan for mining factories



Company information

China factory sale high volume small axial fan for mining factories

Taizhou Hangda Electromechanical Co.,Ltd

1.Founded in 1985, and experienced 20-plus years ups and downs.

2.The company has a team of highly qualified technical staff.

3.The company also carry out technical cooperation with University of Shanghai for Technology and Dalian University Of technology.

4.The products have passed the European CE authentication and the Chinese CCC authentication.

5.The good quality of our products  has won the customer's trusting all over the word.

6.We will make great efforts to provide the high quality product and the good service for the customer.





Factory Size (ters):

10,000-15000square meters



Factory Location:

Linao induster zone,chengnan town, wenling city,zhejiang

province,China



Number of R&D Staff:

5 - 10 People



Number of QC Staff:

Less than 5 People



Contract Manufacturing:

OEM Service Offered   Buyer Label   Offered



Packaging & Delivery

China factory sale high volume small axial fan for mining factories

 The dilivery date depend on order quantity









Main export markets

Market



Revenue(Previous Year)



Total Revenue (%)



South America

confidential

10.82

Southeast Asia

confidential

1.30

Mid East

confidential

1.30

Northern Europe

confidential

64.94

North America

confidential

21.64







Why Choose Us?

GIVE YOU FIVE REASONs!

1.we are a factory foused on fans for more than 29 years .

2.All wires are copper, seamless steel body material, before and after the cover material is aluminum .

3.Every year more than 20000pcs of fans were exported to the other country.

4.Best production capabllity high quality.

5.Gold supplier in alibaba for 4 years.
