Specifications
clinker pulverizing machine for cement1. High crushing ratio
2. High efficiency crusher
3. High capacity
4. Easy adjustment
Clinker Pulverizing Machine For Cement
clinker pulverizing machine for cement,pulverizers for cement production line,cement clinker pulverizer,cement plant crushing equipment,cement machinery:crushers for cement plant
- Cement clinker crushing
At the outlet of the kiln, the clinker goes through a cooler, after which the clinker lumps must be broken before entering the final stage of grinding by tube or vertical mills.
- Cement clinker crushers
In most cases, Hammer crusher is used as clinker crusher and placed at the end of cooler for crushing cooling clinker. Clinker crusher, consist of crusher body, rotor, adjustable crushing plate and gearing, is one of main parts of grate cooler. The hinge pin on the upper cover of crusher body can be opened, so it is convenient to replace crusher hammers. Crushing plate can be adjusted to adjust the distance between hammer brink and crushing plate and control the output size. As we all know, the service life of cement clinker crusher hammer plays a very important role in enterprise production cost. DSMAC determinates to help customers to reduce crushing cost and improve profits by choosing better quality materials for hammer and improving hammer wear resistance.
Type |
Rotor Size(Mm*Mm) |
Capacity |
Spindle Speed (R/M) |
Input Size (Mm) |
Output Size (Mm) |
Motor Power (Kw) |
Overall Dimension (L*W*H) |
XPCF20 |
Φ800*400 |
15-20 |
813 |
120 |
4 |
30-37 |
1320*1529*1578 |
XPCF30 |
Φ800*600 |
20-30 |
813 |
120 |
4 |
37-45 |
1520*1529*1578 |
XPCF40 |
Φ900*600 |
30-40 |
807 |
150 |
5 |
37-45 |
2008*1478*1896 |
XPCF50 |
Φ900*700 |
40-50 |
807 |
150 |
5 |
45-55 |
2008*1578*1896 |
XPCF60 |
Φ900*900 |
50-60 |
807 |
150 |
5 |
55-75 |
1969*1777*1866 |
XPCF70 |
Φ1000*950 |
60-70 |
726 |
200 |
6 |
55-75 |
2337*2054*2167 |
XPCF80 |
Φ1000*1100 |
70-80 |
726 |
200 |
6 |
75-90 |
2337*2208*2167 |
XPCF90 |
Φ1000*1250 |
80-90 |
726 |
200 |
6 |
90-110 |
2337*2359*2167 |
XPCF100 |
Φ1250*1100 |
90-100 |
581 |
250 |
8 |
90-110 |
2915*2153*2480 |
XPCF125 |
Φ1250*1350 |
100-125 |
581 |
250 |
8 |
110-132 |
2915*2375*2480 |
XPCF150 |
Φ1250*1650 |
125-150 |
581 |
250 |
8 |
160-200 |
2915*2669*2480 |
XPCF200 |
Φ1600*1350 |
150-200 |
450 |
300 |
10 |
160-220 |
3178*2604*2810 |
XPCF250 |
Φ1600*1600 |
200-250 |
450 |
300 |
10 |
220-250 |
3174*2906*2809 |
XPCF300 |
Φ1800*1800 |
250-300 |
403 |
350 |
12 |
315-355 |
3788*3250*3100 |
XPCF400 |
Φ1800*2200 |
300-400 |
398 |
350 |
12 |
400-450 |
3862*3663*3500 |
XPCF500 |
Φ2000*2405 |
400-500 |
363 |
350 |
12 |
500-560 |
4141*4046*3774 |
- Main wear parts for Cement clinker crusher: Big Gold Teeth® Crusher Hammers,Sandwich® Super Crusher Hammers,Clinker Crusher Rotor
