DVI 16x8 Switch DVI Matrix Switch
Description:
DVI 16x8 is 16 inputs 8 outputs DVI matrix, the matrix supports DVI 1.0 protocol. Supports high color depth all HDTV
resolutions including 1080p/60, and up to 1920 * 1200 resolution of your PC. Support for long-term input for Auto EQ
of long distance DVI cable compensation, reducing required additional input signal processing device number.
This matrix can be excellent DVI video and multi-channel digital audio signals transmitted via DVI cable to the display device.
Features:
1. Plug-in structure, supports 16-channel VGA signal input, 8-channel output of the DVI signal. Input and output channels can adjust
2. Interface bandwidth of 1.65Gbps, the video bandwidth of 225MHz, and full support for 1080P HD signal.
3. High-speed digital switching technology, the perfect solution crosstalk ghosting and smearing.
100% true to reproduce the effect of the input video signal.
4. Support the type of video signal: DVI1.0 specification DVI-D digital T.M.D.S signals.
5. Video signal inputs and outputs, full-digital DVI-D interface.
6. Long drive: input with automatic equalization, effective in reducing the transmission lines caused deterministic jitter (ISI); o
utput with pre-emphasis function for long cable receiver can still receive signals; input support reception delay,
effective response when the differential pair of lines of unequal length when time compensation;
8. Central control function: extension control board, you can have a programmable central control function, can support 3-way programmable RS232 interface, 3-way infrared transmitter port and support for iphone, ipad, android screen control
9. Power off memory function and live memory function: with off-site protection; may be saved and recalled 18 switching state;
10. Extended Network Control: When the expansion Central control, in addition to used iphone, ipad control of the machine, but also to support remote network control matrix switch;
11. Input and output cards: 36 Series (with) the following each card is two way, more than 36 series, each card 4;
12. Luxury crystal buttons and with light emitting indicator, the current switch information can be obtained directly through the keypad backlight, the operation more convenient;
13. With 1-way RS-232 communication interfaces;
14. Built-in universal power supply.
Customer Service
Supply the continual, high efficiency and speed service to our customers. Establish high quality service brand and perfect service
network.
In order to supply the timely and satisfied service to our customers and to improve the after-sales service, we make promise as following:
We guarantee that we supply the updated and high quality equipment to our customers. Our products can meet your demand fully.
Delivery time: after order confirmation 5-7 working days. If larger order, the delivery time will be longer.
Our products are lifelong maintenance, 1 year guarantee period. The guarantee period begins after it’s used.
Diagram
