150m Signal Extender,Signal Transmition by CAT 5/6,/6e CVBS Extender over Twisted Pair Cable

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Guangzhou
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

150m Signal Extender, Signal Transmition by CAT 5/6, CVBS Extender over Twisted Pair Cable

Overview

AVC CVBS CAT/TR digital twisted pair transmitter transmit video CVBS) signal up to 150m (the CAT6 cable) through the single

CAT5e/6 shielded cable to, and can simultaneously transmit analog stereo audio.

Features

1.Support 1-video signals switch into a single cable transmission;

2.Uncompressed audio and video transmission;

3.Connect with any industrial and commercial display;

4.Support audio and video transmission up to 150m distance.

Parameter

Parameter Name	CVBS Single-cable Transmission Extender
Video signal	Signal type/quantity	1- video(CVBS)
	Interface	1 pc RCA socket
	Signal level	Analog signal :-2v/+2v
	Impedance	75 Ω
	Video signal width	150MHz
	Frequency response	20Hz~20kHz, ±0.05 dB
	Input/output level	2Vrms(Max)
Audio signal	Input/output interface	3.5mm unbalanced stereo audio input
	Gain	0dB
	Frequency response	20Hz~20 Khz
	Total Harmonic Distortion + Noise	0.01%@1KHz(Rated voltage)
	S/N	>80dB at Vin=0 V
	Stereo separation	>80dB @ 1 kHz
	CMRR	>75dB @: 20 Hz ~ 20 kHz
	Signal type	stereo (unbalanced connection)
	Impedance	input>10 kΩ
	Output	50Ω (Unbalanced connection)
	Max input level	+19.5dBu
	Gain deviation	±0.1dB @20 Hz ~ 20 kHz

Product Display

Product Description

Packaging & Shipping

FAQ

1. Why work with us?

1). Rich experience of working with foreign customers.

2). All product we providing are the best quality, comply with CE, FCC and RoHS

3). Rapid and timely service, 24 hours available.

4). 1-5 years guarantee for all our product.

5). World-leading tech, strong technical support team.

6). A company with CE/ROHS

2. How to order?

It is very easy to order if you can determine which product and quantity you need. But if you can't sure which product can best suitable for your needs, our sales will give you best recommend.

3. How to make payment

We support TT / Western Union / MoneyGram for payment, you can chosse the one best suit for you.

You can get account information from our sales.
