Feature
1. Chinese and English programmable screen.
2. Adopt the newest 32 bit SUMSUNG ARM embedded processor,the speed reach to 533MHz..
3. Use highly integrated chip,tha LAY OUT make the system operate steady and fluently.
4. Host buit in 8MB dump,16MB large capacity FLASH storage.
5.With power line carrier communicate function,within 300m can comtrol without line.
6. 8 ports of programmable RS-232 interface,can receive RS232,RS485,Rs422 data.
7. Host serial ring out, serial port 1~8,any input,and any serial port output .
8. 8 port independent programmable IR emmiter ,can be used as serial,the nummbers of programmable can reach to 16 .
9. 8 port digital I/O input/output control interface,with protecting circuit.
10. 8 port light current relay control interface,can control 5 v switching volume.
11.Support remote internet control interface,built-in net interface,don't need extend.
12. 3 CRV-NET internet control interface,can connect with 256 net equipments.
13. Customer can program any control agreement and code.
14.Front and back board with system software transmit interface.
15.Front board with system hardware reset function.
16. Embedded intellignet IR study function ,do not need configure professional study instrument .
17. Support double code, mean one key send two codes.
18. Can exchange IR equipment ,do not need once programme.
19. Can download the commonly used instruments infrared code base.
20.Adopt to the international fashion SMT patch craft.
21.Full standard green power(110v~220v),can be used any place.
Parameter
Processor | |
| CPU | 32 bit ARM micro processor |
| Processor | 210MIPS,the highest reach to 533MIPS. |
Storage | |
| Standard memory | 8M SDRAM,8M flash |
| Extend memory | can extend to 32M |
Control interface | |
| COM port | 8 DB9/M port,can both way extend RS232,RS485,RS422 signal |
| Input I/O port | 8 terminal blocks,protect circuit,support 0-5v digital inout signal |
|
CRV-NET port
|
3 termonal blocks,support CRV-NET control bus |
| Light current relay control port | 8 terminal blocks,independent relay,rated 1A/5V digital input signal |
| Net port | 1 net port |
| Power line carrier port | 1 DB9/F port |
| IR port | 8 ports 3.81mm phoenix |
| Computer manage interface | 1 3.5interface (front board) 1 DB9/F interface (back board) |
| Package | metal box,support rack mount |
| Power | wide voltage universal power supply(110v~240v) |
| Software | control system builder,Chinese and English screen |
| Size9(L×W×H)mm | 485×236×90 |
| Weight | 4.5 kg |
