Remote Central Controller, 7 Inch Touch Screen, Home Automation System, 18x18 Modular and Scalable Video Matrix Switcher
SPLMII is an central controller with 8*8 matrix switcher functions, VGA 4*4 , composite video 4*4/5*3/6*2/7*1, and audio 8*4 matrix switching system (with audio volume adjustment function), are highly integrated.
It is with 8-channel IR port, 4I/O inputs, three programmable serial ports, 32-bit embedded microprocessor, support complex logic computing. 3 programmable outputs serial ports, one serial port is for program downloading, one AVCIT net port, widely used in small and medium sized multifunctional meeting rooms, video conferencing systems, medium and large institutions, intelligent home and other occasions.
SPLM-II
1. 32-bit embedded processor, frequency up to 533MHZ;
2. Highly integrated co processor chip, with fine layout, enable the system running to be stably and efficient;
3. 8 MB of memory and 16 MB flash memory;
4. Programmable control platform, interactive control structure;
5. VGA 4*4 matrix switcher functions, VGA 15HDF interface
6. Optional 4*4/5*3/6*2/7*1 composite video matrix switcher functions, BNC interface;
7. Audio 8*4 matrix switching, 3-bit phoenix interface;
HD1818
1.Modular structure: Input and output signal support all digital and analog formats, such as AV, VGA, YPbPr, DVI, HDMI, HD,SDI, OpricFiber, RJ45, we even developped central controller module, which works with HD1010, HD1818 and HD3636;
2. Long distance driver feature: Input with automatic equalization, effectively reducing ISI due to long distance transmission; Output with pre,emphasis for signals; Input support receiving delay, apply for the time compensation when the differential pair of lines are with unequal length;
3.Connection indicating: Input and output modules are with led lighting once connected;
4.Compatible with HDCP: Make sure that protected media content from Blue-ray DVD, Gane box etc;
AS-7
Touch panel type Industrial grade IPS LCD ;
Size 7 inch
Resolution 1280*800 pixels
Brightness Adjustable
Memory512M (DDR2)
Contrast9 levels adjustable
Backlighting LED
Screen ratio 16:9
Touch panel life 10,000,000 times
1. Why work with us?
1). Rich experience of working with foreign customers.
2). All product we providing are the best quality, comply with CE, FCC and RoHS
3). Rapid and timely service, 24 hours available.
4). 1-5 years guarantee for all our product.
5). World-leading tech, strong technical support team.
6). A company with CE/ROHS
2. How to order?
It is very easy to order if you can determine which product and quantity you need. But if you can't sure which product can best suitable for your needs, our sales will give you best recommend.
3. How to make payment
We support TT / Western Union / MoneyGram for payment, you can chosse the one best suit for you.
You can get account information from our sales.
