Extra WIFI function, Supported RF communicating with controller, Home automation control panel, 10 inch Wired/RF touch panel AS-10
10.1 inch TFT-LCD display, with high quality graphical performance, support picture-in-picture, picture out picture, and screen overlay function, adjustable transparency ratio, any size of video window. Thanks to ARM Cortex-A7 4-core 2GHz CPU, and 2GB RAM, even more editable space, and even faster operating experience are available for user, which is amazing.
AS-10 TFT-LCD display, resolution: 2048x1536 (QXGA)
l Extra WIFI function available, bi-directional communication;
l Supported RF communicating with controller, directional communication;
l Jump page and subpage display;
l With English and Chinese version;
l Large capacity lithium-ion battery and an external DC12V power supply;
l USB for data exchange;
l Input deviation less than±0.2mm;
l Delay standby, shutdown delay, network ID, volume, brightness are adjustable;
l Reliable function of automatic shutdown and wake up;
l Feedback sound and voice tips are customizable by your own WAV format files;
l Nice calendar and weather display;
l Simply slide on panel, to adjust volume and brightness, and unlock screen;
l Rich animation and template options;
l Support dynamic graphics and text, Special custom designs, such as user friendly interface, temperature and lighting display, is available;
l Detect and link to controller automatically;
l Video window zoom in/out functions.
Processor Quad-core ARM Cortex-A7, 256KB L1 cache, 1MB l2 cache
Kernel Cortex A7
Number of cores Quad-core
Process 40 nm
Clock speed 1.0GHz
Network mode WIFI, reserved 3G ports
GPUI magination Power VR SGX544MP2, 8 logical cores, compatible with OpenGL ES 2.0, OpenCL 1.x, DirectX 9_3
RAM 2G DDR3
Storage 4G nand flash
Size 10.1 inches
Resolution 2048x1536(QXGA)
Screen ratio 4:3
Gross weight 134g(Max)
Surface of LCD Mirrors, Hard coating (3H), anti reflection
Brightness 440 cd/m2
Contrast 800:1
Display colors 16.7M(8-bit)
Battery 10000mAh
1. Why work with us?
1). Rich experience of working with foreign customers.
2). All product we providing are the best quality, comply with CE, FCC and RoHS
3). Rapid and timely service, 24 hours available.
4). 1-5 years guarantee for all our product.
5). World-leading tech, strong technical support team.
6). A company with CE/ROHS
2. How to order?
It is very easy to order if you can determine which product and quantity you need. But if you can't sure which product can best suitable for your needs, our sales will give you best recommend.
3. How to make payment
We support TT / Western Union / MoneyGram for payment, you can chosse the one best suit for you.
You can get account information from our sales.
