AV Control System, Central Controller, 7 Inch Touch Panel, 64x48 HDMI Matrix, RGB Matrix Switcher
E-CP3R is a modular controller which is driven by the market need. Ithas a unique dual-system structure, with hot backup function, independent modules design, simply enable the custom-made to be so easy, flexible function modules can be widely applied in various fields such as large exhibition hall, smart villa, government conference etc.
It is born to be the pioneer who is leading the revolutionary transforming in central controller industry
AS-7 inch wireless IPS touch panel, communicates with central controller via Wifi/RF/wired, user-friendly and graphical interface for programming supports pictures, graphics, text, animation, 3D buttons and so on, with a high graphical performance.
AVC-RGBHV6448 is matrix switcher for RGBHV,RGBS,RGsB,RsGsBs,HDTV,S-video,Composite video signals. It can route any 64 or all 64 inputs to any 48 or all 48 outputs simultaneously.Embedded intelligent control and management software, RS232 control interface.
E-CP3R
1) Dual system backup efficient embedded ARM processors, a powerful dual processing capabilities to protect the host system;
2) Dual mother board configuration, enhanced integrated motherboards, something wrong with one motherboard, the other continue to work;
3) Dual power supply modules, high performance wide-voltage power supply to ensure reliability;
4) Custom made functions. Revolutionary modular and flexible structure, functions can be custom made according to your project
5) Support iOS/Android and AVCIT touch panels, Works with all iOS/Android devices, like iPad, iPhone, and our own wired/wireless/RF touch panels;
AS-7
1.7-inch IPS touch screen, touch-screen resolution is 1280*800 pixels;
2.Communicates with central controller via Wifi (Maximum distance depending on router), Jump page and subpage display function;
3.With English and Chinese version;
4.Graphical interface for programming is editable, supports pictures, graphics, text, animation, 3D buttons and so on;
5.Large-capacity lithium-ion battery, DC 5V power supply;
6.Data downloading by USB, standby delay, network ID, volume and brightness is adjustable;
RGB6448
(1)Video bandwidth up to 450MHz (-3dB), fully loaded. Resolution support 1920 × 1440 @85Hz;
(2)Provide multiple sets of default save option, the current switching state power and memory;
(3)LCD time display switching operation status, and can query the current matrix input / output channels connected contact state;
(4)Front panel with touch-button interface, ergonomic;
(5)Compatible with multiple control methods: AVC-NET bus,RS232, button operation, supporting software,Infrared remote control (optional).
Parameter Name |
RGB6448 |
|
Signal input |
Signal Type |
computer RGBHV |
Connection Type |
RGBHV BNC input |
|
Input/output level |
0.5V~2.0Vp-p |
|
IO Impedance |
75Ω |
|
Echo loss |
-30dB @ 5MHz |
|
Maximum DC Compensation |
1.5V |
|
Signal output |
Signal Type |
computer RGBHV |
Input/output level |
0.7V~2.0Vp-p |
|
IO Impedance |
75Ω |
|
Echo loss |
-30dB@5MHz |
|
Maximum DC Compensation |
+5mV-0 |
|
Bandwidth performance |
Bandwidth |
450MHz(-3dB) fully loaded |
Brightness crosstal |
-50dB@5MHz,-45dB@10MHz |
|
Maximum propagation delay |
5 ns (+1 ns) |
|
Switching speed |
200 ns (maximum time) |
|
Specification |
Power supply |
220V/50Hz |
Power: |
28W |
|
Installation |
With a standard rack mount |
|
Mean time between failur |
50,000 hours |
|
1. Why work with us?
1). Rich experience of working with foreign customers.
2). All product we providing are the best quality, comply with CE, FCC and RoHS
3). Rapid and timely service, 24 hours available.
4). 1-5 years guarantee for all our product.
5). World-leading tech, strong technical support team.
6). A company with CE/ROHS
2. How to order?
It is very easy to order if you can determine which product and quantity you need. But if you can't sure which product can best suitable for your needs, our sales will give you best recommend.
3. How to make payment
We support TT / Western Union / MoneyGram for payment, you can chosse the one best suit for you.
You can get account information from our sales.
