High Quality S-400 Switching Power Supply

High Quality S-400 Switching Power Supply thumbnail-1
High Quality S-400 Switching Power Supply photo-1
US$ 12.2 - 20.5 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
KASAN/OEM/NEUTRAL
Model Number:
S-400
Contact Supplier Request Quote Chat Now
Yueqing Kasan Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name KASAN/OEM/NEUTRAL
Model Number S-400
Output Power Other, 400W
Output Type Single
Input Voltage Other, full range
Output Voltage full range

Specifications

High quality S-400 switching power supply
1.Universal input voltage
2..10Years Experience Factory
3.2 years warranty

High quality S-400 switching power supply



1. Our company is a professional manufacture and OEM.
Our products obtain CE and ISO9001 Certificate and according to IEC 521 international standard to.
2. Low price and high reliability
105 C output capacitor
AC input power suitable for the world
Hight efficiency and low operation temperature
Soft-start current can reduce the AC input impact effecticly
With Short-circuit and owwerload protection
Compact size, light weight
100% full-load burning test
Installed with EMI filter, minimum wave

Model  /  Specification SP-400-9 SP-400-12 SP-400-13.5 SP-400-24 SP-400-48
DC  output  voltage 9V 12V 13.5V 24V 48V
Output  voltage  error ± 1% ± 1% ± 1% ± 1% ± 1%
Rated  output  current 43A 33A 29A 17A 8.3A
Output  current  rage 0-43A 0-33A 0-29A 0-17A 0-8.3A
Wave  and  noise 150mVp-p 150mVp-p 150mVp-p 150mVp-p 200mVp-p
Inlet  stability ± 0.5% ± 0.5% ± 0.5% ± 0.5% ± 0.5%
Load  stability(Note5) ± 0.5% ± 0.5% ± 0.5% ± 0.5% ± 0.5%
DC  output  power 387W 396W 400W 400W 400W
Efficiency 78% 83% 85% 85.5% 86%
Adjustable  range  for  DC  voltage ± 10% ± 10% ± 10% ± 10% ± 10%
AC  input  voltage  range 170~264VAC
AC  Input  current 5.6A/115V  2.8A/230V
AC  impulse  current 40A/230V
Leakage  current < 3.5mA/240VAC
Overload  protection 105%~135%  Type  :   PULSING  HICCUP  SHUTDOWN  Reset:   auto  recovery
Over-voltage  protection 13.8~16.2V 15.5~18.2V 18~21V 27.6~32.4V 31~36.5V 57.6~67.2V
Fan  control, O. T. P. RTH3> =60º C~70º C  FAN  ON, < =55º C~60º C  FAN  OFF, > =80º C~85º C  Cut  off  output
Temperature  coefficient ± 0.03%º C(0~50º C)
Setup  rise  hold  up  time 1.5s, 50ms, 20ms
Vibration 10~500Hz,   2G  10min. /1cycle, Period  for  60min, EACH  AXES
Withstand  voltage Input  and  output  interval  :   3KVAC, Input  and  enclosure  :   1.5KVAC  Output  and  enclosure  :   0.5KVAC
Isolation  resistance Input  and  output  interval  ,   Input  and  enclosure  ,   Output  and  enclosure  :   500VDC/100M  Ohms
Working  temperature  and  humidity -10º C~+50º C, 20%~90%RH
Store  temperature  and  humidity -20º C~+85º C, 10%~95%%RH
Overall  dimension 241  x  124  x  65mm
Weight 1.2Kgs
Safety  standards UL1950, TUV  EN60950
EMC  standards EN55022, EN1000-4, 2, 3, 4, 5, 6, 8, 11  IEC100-3-2
Note: 1. The  testing  condition  for  the  parameter  above  is: 230VAC  input,     rated  load, 25º C  70%Rh, Humidity
2. Error, include  the  setting  error,   line  stability  and  load  stability. (Note: 5)
3. Wave  test: adopting“ A12” double  wire  for  20MHz, and  0.1uF& uF  capacitor  short-circuit  for  interrupting
4. Inlet  voltage  stability  test:   when  is  over  load,   the  lowest  voltage  of  inlet  is  representative  to  the  highest  voltage.
5. Load  stability  test:   The  load  is  from  0%  to  100%, others  60%.
6. C2  , 3,   11must  be  knocked  down.





High quality S-400 switching power supply
