Help CenterFull Automatic Voltage Regulator&SVC Three Phases Voltage Stabilizer
Related Products
-
Full Automatic Voltage Regulator SVC SeriesNegotiableMOQ: 100 Pieces -
Full Automatic Voltage Regulator Three Phases 6KVA High AccuracyNegotiableMOQ: 100 Pieces
-
SVC-2000W SVC Fully Automatic Voltage StabilizerNegotiableMOQ: 1000 Pieces
-
SVC Fully Automatic Voltage StabilizerNegotiableMOQ: 1000 Pieces
-
SVC 3000VA FULLY Automatic Voltage StabilizerNegotiableMOQ: 1000 Pieces
Specifications
1.Wide voltage range2.Input voltage display,output voltage display
3.Output delay time selectable
Specifications:
1)Input voltage:160-270V
2)Output voltage:220 10%
3)Phase:single-phase or three-phase
4)Frequency:50/60HZ
5)Ambient temperature:-5~+40c
6)Ambient humidity:less than 90%
7)Temperature rise(input voltage200v,output voltage 220v and rated load):less than 75°C
8)Insulation resistance:more than 3m at DC 500v
Specification |
SBW- 30KVA |
SBW- 50KVA |
SBW- 80KVA |
SBW- 100KVA |
SBW- 150KVA |
SBW- 200KVA |
SBW- 225KVA |
SBW- 250KVA |
SBW- 320KVA |
SBW- 350KVA |
SBW- 400KVA |
SBW- 500KVA |
SBW- 600KVA |
SBW- 800KVA |
SBW- 1000KVA |
||||||||
Input |
Phase |
Three phase |
|||||||||||||||||||||
Voltage |
304V-456V |
||||||||||||||||||||||
Frenquency |
50Hz/60Hz |
||||||||||||||||||||||
Output |
Voltage |
380V±3% |
|||||||||||||||||||||
Frenquency |
50Hz/60Hz |
||||||||||||||||||||||
Protection |
Low voltage |
318V±7V |
|||||||||||||||||||||
Over voltage |
426V±7V |
||||||||||||||||||||||
Bypass |
Auto/Manual Optional |
||||||||||||||||||||||
Overload/short circuit |
YES |
||||||||||||||||||||||
Shipping Wt.(Kg) |
280 |
320 |
430 |
480 |
560 |
680 |
720 |
800 |
1040 |
1080 |
1106 |
1490 |
1580 |
2400 |
3150 |
||||||||
Packing dimensions(mm) |
800*620*1380 |
850*630*1520 |
1050*750*1800 |
1100*900*1850 |
1100*920*1900 |
1300*1050*2000 |
1050*750*2000 |
||||||||||||||||
Efficiency |
AC-AC |
>95% |
|||||||||||||||||||||
Acoustic |
Noise level |
≤50dB |
|||||||||||||||||||||
Environment |
Temperature |
-5 to 45 |
|||||||||||||||||||||
Humidity |
20% to 90% |
||||||||||||||||||||||
