11KV Oil Immersed Distribution Transformer

11KV Oil Immersed Distribution Transformer thumbnail-1
11KV Oil Immersed Distribution Transformer photo-1
US$ 500 - 2,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
KASAN/OEM/NEUTRAL
Model Number:
S-11
Contact Supplier Request Quote Chat Now
Yueqing Kasan Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name KASAN/OEM/NEUTRAL
Model Number S-11
Usage Other, Electrical power supply
Phase Three
Coil Structure Toroidal
Coil Number Other, deplex winding

Specifications

This oil immersed distribution transformer is widely used in power supply system.

S11-M Oil-immersed Power Transformer



Product Description:
Oil-Immersed Transformer can serve both indoors and outdoors at an ambient temperature up to 400C. With reasonable structure, they are capable to withstand short-circuit and overload, and they are free of maintenance and easy to repair.
Functional characteristics
Technical Parameters
Rated Capacity (KVA): 10~6300 KVA
Vecor Group: Yyn0 or Dyn11
Impedance Voltage (%): 4%, 4.5%(Or as customer requirement)
Rated voltage: H. V: 11, 10.5, 10, 6.3, 6KV (Or as customer requirement)
L. V.: 0.4 KV (Or as customer requirement)
Tapping range: +/- 5% or +/- 2 * 2.5% (Or as customer requirement)
Frequency: 50Hz
Number of phases: 3
Cooling method: ONAN or ONFN
Temperature rise limits: Winding ≤ 65K
Top oil ≤ 60K
Standards: GB1094 Power transformer
GB/T6451 Technical data & requirement of three-phase oil immersed power transformer
IEC60076 Power transformer
Service conditions
Normal service conditions:
1) Altitude: ≤1, 000m
2) Highest ambient temperature: +40
3) Highest annual average temperature: +20
4) Indoor and outdoor
5) Highest daily average temperature: +30
6) Lowest temperature: -25
7) We can also provide transformers operated in special conditions according to users'.

Standard: IEC60076
Origin: China
Packing: export packing
Transportation: Sea









For more information, special requirement, please contact us.

Trademark: CHHG
Model: S11-M-30~2000/11
Standard: IEC60076

Rated power (kVA)

Voltage combination and tapping range (kV)

Connection symbol

No-load Current (%)

Loss (W)

Impedance (%)

Gross weight (kg)

HV

LV

No-load

load

10

6.0±5% Or 11 ±5%

0.4

Yyn0 Or Dyn11

3.8

55

310

4.0

245

20

3.0

80

475

290

30

2.1

100

600

330

50

2.0

130

870

410

63

1.9

150

1040

480

80

1.8

180

1250

560

100

1.6

200

1500

690

125

1.5

240

1800

880

160

1.4

290

2200

940

200

1.3

340

2600

1160

250

1.2

400

3050

1320

315

1.1

480

3650

1550

400

1.0

570

4300

1730

500

1.0

680

5150

2190

630

0.9

840

6200

4.5

2460

800

0.8

980

7500

2750

1000

0.7

1150

10300

3220

1250

0.6

1360

12000

3800
