Help Center2P QA17C MINI BLACK CIRCUIT BREAKER
Related Products
|
SA AF QA QF and DIN Ranges
| |||||||
| 1. Special Earth Leakage Protection Devices | Earth Leakage protection Devices Abbreviation Codes | ||||||
| All Products manufactured by CBI to meet special non-standard requirements of customers | Suffix A Earth leakage protection device with overload. Single pole and Neutral / 3 pole and Neutral versions | ||||||
| 2. Standard Current Ratings | |||||||
| Ampere ratings indicated are standard. Non-standard ratings can be provided (POR) | Suffix C Earth leakage protection device ( switch disconnector) single pole and 3 pole versions | ||||||
| 3. Earth Leakage Protection Device Sensitivities | |||||||
| Sensitivities indicated are standard. Non-standard sensitivities can be provided (POR) |
Suffix D Din Rail Mounting only (Escutcheon Height 45MM
|
||||||
|
Residential +Commercial/ Industrial Clip in Earth Leakage Protection
| |||||||
|
Residential Earth Leakage Protection Device Single Device Single Phase with Overload Protection
| |||||||
| Type | Poles | Voltage | KA | MA | Width (mm) | Rating (A) | STD Pack |
| QA17A | 1+N | 230VAC | 2.5 | 30 | 26 | 15 20 30 40 50 63 | 10 |
|
Residential Earth Leakage Protection Device (Switch Disconnector) single Phase without overload protecton
| |||||||
| QA17C | 1+N | 230VAC | 2.5 | 30 | 26 | 63 | 10 |
|
Residential Earth leakage Protection Device, 3 phase with overload protection
| |||||||
| SA36A | 3+N | 415VAC | 2.5 | 30 | 78 | 15 20 30 40 50 63 | 5 |
|
Residential Earth Leakage Protection Device (Switch Disconnector) 3 phasw withour overload protection
| |||||||
| SA36C | 3+N | 415VAC | 2.5 | 30 | 78 | 60 | 5 |
|
Commerical/ Industrial Earth Leakage Protection Device Single phase with overload protection
| |||||||
| QF17A | 1+N | 230VAC | 5 | 30 | 26 | 15 20 30 40 50 63 | 10 |
| QF14A-D | 1+N | 240VAC | 6 | 30 | 36 | 6 10 16 20 30 40 50 63 | 10 |
|
Commerical/ Industrial Earth Leakage Protection Device, Single Phase with overload protection. Mini Rail Mounting
| |||||||
| SF15A | 1+N | 240VAC | 5 | 30 | 65 | 80 100 | 10 |
|
Commercial/ Industrial Earth leakage protection Device (Switch Disconnector) Single Phase without overload portection
| |||||||
| QF17C | 1+N | 230VAC | 5 | 30 | 26 | 63 | 10 |
| QF14C-D | 1+N | 240VAC | 6 | 30 | 26 | 63 | 10 |
Introduction of company
Yueqing KASAN Electric Co.,LTD, is one of the best manufacturer and exporter companies in Liushi,Wenzhou. We specialize in export various low voltage electrical products with over 50 series and more than 6000 specifications have been producing electrical goods for more than 10 years in this line, which also a BV assessed gold supplier on Alibaba.
Our Promise to customer:
1. Quality Guarantee
2. Delivery time guarantee
3. Provide superior service to fit customer need
Q 1: what is your minimum order quantity for whole of your products ?
A1: Most of the items no have MOQ requirement, you can even buy 1pc
Q 2: how about the delivery time ?
A 2: It depend on your order quantity, some items we have in stock, but some items need produce.
Q 3: Could you offer Form A or C/O ?
A3: It totally no problem. We can issue Form A and C/O as per customer’s need once boat leave.
Q 4: Would you accept OEM ?
A 4: OEM. totally no problem for us. But it require bigger Q’ty than normal.
Q 5: We want to know month capacity.
A 5: 360000pcs/month
Q 6: Where is your market?
A6:Our products are popular in US,UK,Ireland,Sweden,France,South of America, Asia, many of Africa countries and so on.
Q 7: what kind of certificate you have ?
A 7: Our company already achieve ISO, and for products, we have CE, SEMKO,CB, VDE(pending) .
Q 8: what kind of payment terms can you offer ?
A 8: Normal terms of payment in international business such as T/T, Western Union, Paypal, L/C at sight
Usual way of payment for by sea goods:
30% advance ,70% balance before shipment
Compensation term:
Q9: If we bought your products, but found quality problem, how to solve?
A9: After confirmed, if the quality problem is caused by us not for outer sector,We will compensate each piece to customer.
