GMC-40,65 AC Contactor Gmc Contactor Auxiliary

GMC-40,65 AC Contactor Gmc Contactor Auxiliary thumbnail-1
GMC-40,65 AC Contactor Gmc Contactor Auxiliary photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
KASAN
Model Number:
GMC 50.65.75.85
Contact Supplier Request Quote Chat Now
Yueqing Kasan Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo shanghai etc.
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name KASAN
Model Number GMC 50.65.75.85
Electricity Type AC
Number of Pole 3
Phase 3
Main Circuit Rating Voltage 600v
Main Circuit Rating Current 150a

GMC AC Contactor,LS Contactor



     GMC(LS) series AC contactor is suitable for using in the circuits up to the rated voltage 660VAC 50Hz or 60Hz, rated current 9A to 125A, making and breaking and frequent starting, controls the AC motor. Combined with the auxiliary contact group, air delayer, machine interlocking device etc, it is combined into the delay contactor, mechanical interlocking contactor, drat-delta starter, with the thermal relay, it is combined into the electro magnetic starter. This product conforms to the requirement of IEC 60947 4 -1 & GB14048.4 standards .

Contactor Application

Type GMC-40 GMC-50 GMC-65 GMC-75 GMC-85
IEC-60947 AC 1 duty 60A 80A 100A 110A 135A
AC3 duty 200-240V 11KW40A 15KW55A 18.5KW65A 22KW75A 25KW85A
380-440V 18.5KW40A 22KW50A 30KW65A 37KW75A 45KW85A
500-550V 22KW32A 30KW43A 37KW60A 45KW64A 45KW75A
690V 22KW25A 30KW33A 37KW33A 45KW47A 45KW52A
UL Continuous current (Ith) 50A 70A 80A 90A 100A
AC motor Single phase 115V 3HP 3HP 5HP 5HP 7.5HP
230V 5HP 7.5HP 10HP 15HP 15HP
Three phase 200V 10HP 10HP 15HP 20HP 25HP
230V 10HP 15HP 20HP 25HP 30HP
460V 25HP 30HP 40HP 50HP 50HP
575V 25HP 30HP 40HP 50HP 50HP
Life time (unit:10,000 time) Electrical 200 200 200 200 200
Mechanical 1500 1000 1000 1000 1000
ntact standard 2NO2NC 2NO2NC 2NO2NC 2NO2NC 2NO2NC



 GMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliary









GMC-40,65 AC Contactor gmc contactor auxiliary

GMC-40,65 AC Contactor gmc contactor auxiliary

Yueqing KASAN Electric Co.,LTD, is one of the best manufacturer and exporter companies in Liushi,Wenzhou. We specialize in export various low voltage electrical products with over 50 series and more than 6000 specifications have been producing electrical goods for more than 10 years in this line, which also a BV assessed gold supplier on Alibaba.

Our Promise to customer:

    1.     Quality Guaranteed

    2.     Delivery time guarantee

    3.     Provide superior service to fit customer need

GMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliary

GMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliaryGMC-40,65 AC Contactor gmc contactor auxiliary

FAQ:



Q 1: what is your minimum order quantity for whole of your products ?
A1: Most of the items no have MOQ requirement, you can even buy 1pc



Q 2: how about the delivery time ?
A 2: It depend on your order quantity, some items we have in stock, but some items need produce.



Q 3: Could you offer Form A or C/O ?
A3: It totally no problem. We can issue Form A and C/O as per customer’s need once boat leave.



Q 4: Would you accept OEM ?
A 4: OEM. totally no problem for us. But it require bigger Q’ty than normal.



Q 5: We want to know month capacity.
A 5: 360000pcs/month



Q 6: Where is your market?
A6:Our products are popular in US,UK,Ireland,Sweden,France,South of America, Asia, many of Africa  countries and so on.



Q 7: what kind of certificate you have ?
A 7: Our company already achieve ISO, and for products, we have CE, SEMKO,CB, VDE(pending) .



Q 8: what kind of payment terms can you offer ?
A 8: Normal terms of payment in international business such as T/T, Western Union, Paypal, L/C at sight



Usual way of payment for by sea goods:



30% advance ,70% balance before shipment



Compensation term:



Q9: If we bought your products, but found quality problem, how to solve?



A9: After confirmed, if the quality problem is caused by us not for outer sector,We will compensate each piece to customer.
