Vacuum Controller VC100B, Auto Measure/hold Desired Vacuum Rate for Target System
US$ 810 - 1,050
MOQ: 1 Set
Key Specifications
Get Latest Price
Product Type:
Other, Vacuum Controller
Place of Origin:
Shanghai, China
Brand Name:
SENCO
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Vacuum Filter VF20SUS$ 950 - 1,052MOQ: 1 Set -
SHB-5 Water Circulation Vacuum Pump , Simple Maintenance,Can Resist Certain Corrision, No Ues in ExplosiveUS$ 341 - 455MOQ: 1 Set
-
2XZ-2 Vane PumpUS$ 300 - 540MOQ: 1 Set
-
DL-2004 Cooling Circulator / Chiller -- for 5L Rotary Evaporator & Reactor, SENCO, ChinaUS$ 1,300 - 1,530MOQ: 1 Piece
-
DL2010-Cooling Circulator / Chiller for 10L Below System , SENCO, ChinaUS$ 2,000 - 2,500MOQ: 1 Set
Product Type
Other, Vacuum Controller
Place of Origin
Shanghai, China
Brand Name
SENCO
Model Number
VC100B
Specifications
- To measure vacuum rate in target sys.- To control sys vacuum at desired automatically
- Prevent vapor escaping into air
VACUUM CONTROLLER -- SENCO Made
Measure Range: 0~105kPa
Set Range: 1.0~90kPa
Sensitivity: 0.1kPa
Load Capacity: 220V, 370W
(Not for pumping of gas with powder or grain!)
Set Range: 1.0~90kPa
Sensitivity: 0.1kPa
Load Capacity: 220V, 370W
(Not for pumping of gas with powder or grain!)
Demensions(cm):30*20*48H
Vacuum Controller is applied to control vacuum rate for various evaporators. To keep at a right vacuum rate is able to fulfill high speed and stable vaporizing under desired boiling point; high rate receiving of solvent; environment protection from pollution from escaped solvent.
Constant vacuum rate offerred by Vacuum Controller is espectially useful for separating critical mass mixture.
Constant vacuum rate offerred by Vacuum Controller is espectially useful for separating critical mass mixture.
MAIN FUNCTIONS :
- To set and monitor vacuum level of target apparatus, to control and keep constant vacuum rate set, and show the rate;
- Equipped with quick responding electromagnetic valve and bump bottle, is able to keep sealing performance of target apparatus and prevent polluted liquid reflux from vacuum pump to vacuum system during operation.
- By offering power socket for vacuum pump, it can control vacuum pump to have interval working directly, so to prolong service life of vacuum pump greatly.
- Pump nozzle equipped with one cold trap which is able to trap solvent vapor from being sucked into vacuum pump, so to reduce solvent damage to pump and pollution to working environment.
- Apply SUS316L sensor, is adaptable in more applications.
- To set and monitor vacuum level of target apparatus, to control and keep constant vacuum rate set, and show the rate;
- Equipped with quick responding electromagnetic valve and bump bottle, is able to keep sealing performance of target apparatus and prevent polluted liquid reflux from vacuum pump to vacuum system during operation.
- By offering power socket for vacuum pump, it can control vacuum pump to have interval working directly, so to prolong service life of vacuum pump greatly.
- Pump nozzle equipped with one cold trap which is able to trap solvent vapor from being sucked into vacuum pump, so to reduce solvent damage to pump and pollution to working environment.
- Apply SUS316L sensor, is adaptable in more applications.
| VC100B | |
| Measure Range | 0~105kPa |
| Set Range | 2.0~90kPa |
| Sensitivity | 0.1kPa |
| Load Capacity | 220V, 370W |
| Power | 220V, 50/60Hz |
| Dimensions (cm) | 34x16x39H |
