20L Multifunctional Reactor-SENCO China Made -optional Function

20L Multifunctional Reactor-SENCO China Made -optional Function thumbnail-1
20L Multifunctional Reactor-SENCO China Made -optional Function photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
SENCO
Model Number:
20L MultiFunctional Reactor
Contact Supplier Request Quote Chat Now
Senco Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name SENCO
Model Number 20L MultiFunctional Reactor

Specifications

MultiFunctional Reactor F20H Series
-Capacity: 20L
-Features: Integrated Reaction Flask, Incline Stereo Stir, Heating Sys Incl



  Standard Model F20H F20H2A F20H2B
Parameters 1 Reaction Flask (L) 20L 20L,Bottom Discharge 20L,Bottom Discharge
2 Neck No. of Reaction Flask 5 5+1 7+1
3 Rotation Speed (rpm) 40-720 40-720 40-720
4 Toque (Ncm) 160 160 160
5 Bath Power (kW) 3kW 3kW 2kW
6 Static Temp. Control Range & Wave (°C) 0-180 ±0.2 0-180 ±0.2 0-180 ±0.2
7 Bath Size, Capacity, Material Ø45x27, 40L, SUS304 Ø45x27, 40L, SUS304 Ø45x27, 40L, SUS304
8 Power 220V, 20A 220V, 20A 220V, 12A
9 Dimensions (cm) 60x53x160H 60x53x160H 60x60x160H
Configurations 10 Frequency Conversion Speed Control - Y - - Y - - Y -
11 Digital Display Bath Temp., Rotation Speed Bath Temp., Rotation Speed Bath Temp., Rotation Speed
12 PTFE Seal Assembly - Y - - Y - - Y -
13 Bottom Discharge / - Y - - Y -
14 PTFE Flush Type Discharge Valve / - Y - - Y -
15 Charging Valve - Y - - Y - - Y -
16 Temp. Measure Neck - Y - - Y - - Y -
17 Vacuum Meter * - Y - - Y - - Y -
18 Inclined Stereo Stir - Y - - Y - - Y -
19 Auto CW/CCW Stir * - O - - O - - O -
20 Bath Drain - Y - - Y - - Y -
21 Multi-functional Wide Neck (F120) - Y - - Y - - Y -
22 Wide Neck Extension Cap (B24x3) - O - - O - - Y -
23 Wide Neck Cap Holder - O - - O - - Y -
24 Reflux Condensing - Y - - Y - - Y -
25 Distillation Receiving * - O - - O - - O -
26 Liquid Separation * - O - - O - - O -
27 Rectification-Receiving * - O - - O - - O -
28 Drip System (5L) - O - - O - - O -
29 Drip Set (0.1~1L) - O - - O - 1L
30 Cooling Coil * - O - - O - - O -
31 Bath Cap - O - - O - - O -
32 Sampling Bottle / - O - - O -
33 Low Speed Power Stir * - O - - O - - O -
34 Underlay Base (20cm) / - O - - O -
35 Lockable Wheels (8cm) * - O - - O - - Y -
36 Bath Liquid Stir * - O - - O - - Y -
37 Bath Heat Isulation * - O - - O - - Y -
Safety Features 36 Over-current Protection - Y - - Y - - Y -
37 No-spark Electronic Control - Y - - Y - - Y -
38 Independent Overheat Cut-off / / - Y -
39 Dry Heating Protection / / - Y -
40 Ex-proof / Air driven Motor * Available for discussion Available for discussion Available for discussion
Symbol Instruction: - Y - (Equipped), - O - (Optional), - / - (N/A) ( * - Only available when ordering of product, not for separate sale)

SENCO is a reputed top brand among Chinese Suppliers in Rotary Evaporators and Reactors. She is professional in D&E, Manufacturing and Oversea Customer Support.

It is a technology oriented company with professor and engineering team who have developed quite some patented unique technologies and designs which make SENCO products featured in Safe, Durable and Efficient.
Hope you will have chance to try our services, products, to work with our people.
A different experience-- Simple & Relex

S
20L Multifunctional Reactor-SENCO China made -optional function20L Multifunctional Reactor-SENCO China made -optional functionNCO Reactor, Glass Reactor, Oil Bath, High Vacuum, 50L, 20L, Integrative Reaction Flask, PTFE Bottom Discharge, Incline Ster
eo Stir, Frequency Conversion Stir, Multi-Func. Wide Opening, Auto Bi-directional Stir (CCW)
