Help CenterAutomatic Plastic Dry Wall Steel Profile Roll Forming Machine for Vacuum Formed Plastic
Related Products
-
Automatic Plastic Blister Forming Lid Machine for CupsUS$ 7,000 - 14,000MOQ: 1 Set -
Automatic Plastic Blister Cutting Machine for Cup/lid /trayUS$ 7,000 - 14,000MOQ: 1 Set
-
Automatic Plastic Vacuum Forming Machine for Vacuum Forming Thick Plastic SheetUS$ 7,000 - 14,000MOQ: 1 Set
-
Automatic Plastic Small Egg Tray Machine for Vacuum Formed PlasticUS$ 7,000 - 14,000MOQ: 1 Set
-
Automatic Plastic Small Thermoforming Machine BlisterUS$ 7,000 - 14,000MOQ: 1 Set
Specifications
dry wall steel profile roll forming machine1. Good for PS, PET,PVC lid forming
2. PLC control
3. Punching frequency:15-30
dry wall steel profile roll forming machine
Characteristic:
This plastic forming machine is used for molding the plastic material as BOPS/HIPS/PS/PVC/PET and so on, which is widely used for the minitype soup spoon/ the cover of the dish such as the salver of medicine and coffee, the bottleneck of Coca-cola, tray ....
The machine integrates of electricity and optics the technology like: PC auto-controlling, transducer regulating, the piece of material heated up by temperature, molding by air-press to cutting the finished product, and the numbers of the products can input to the machine. The flow is in a high automatic fuction. It is configure the PLC computer control.
Main Technical Parameter
Model |
DDP-420C |
Application |
Used for minitype soup spoon ,the cover of the dish such as the salver of medicine and coffee ,the bottleneck of coca-cola ,tray …… |
Suitable Materials |
BOPS HIPS PS PVC PET |
Max Foaming Area (mm) |
420×160mm / 420×280mm(special design) |
Max.Forming Depth (mm) |
35mm / 55mm(special design) |
Thickness Range of Sheet (mm) |
0.1-1mm |
Max Sheet Roller Diameter (mm) |
710mm |
Max. Rewinding Diameter (mm) |
420mm |
Max Cutting Length (mm) |
160mm / 280mm(special design) |
Air Pressure (mpa) |
0.4-0.7MPa |
Air Consumption (liters/min) |
≥0.3(m 3/h) |
Water Consumption (liters/min) |
Use of water cooling or chiller cooling |
Max Speed |
8-32 time/min |
Power Supply |
according to customer local requirement and amendment |
Heating Power (KW) |
3kw / 6kw |
Totally Power (KW) |
380V 50HZ 5KW |
Weight (kg) |
1000kg |
Dimension (mm) |
3000×950×1500mm |
Some Part of this Machine:
Samples:
We hope to have the opportunity to invite you join our customer team. We will do our best to serve you!
