Small multi-function vertical bottle packing machine
Main Characteristics
Mechanical driving, variable frequency speed regulating, protection of automatic stop when the machine is over loaded;
Control with PLC program, automatically check the miss filling of medical plate and instruction book. Automatic waiting when there is no medical plate;
Equipped with the device for counting finished productsand intelligent fault display
Main Technical Parameter
Running speed |
50~90(boxs/min) |
Size Range of |
≥70X35X12mm |
≤125X100X50mm | |
special machine≤160X100X60mm | |
Size of unfolded leaflet |
(80~180)X(100~190)mm |
Quality of Operation Manual |
55~70g/m2 |
Main Motor Power |
0.75kw |
Power |
three phase four wire system 380V 50Hz |
Air-compress |
0.6~0.7MPa |
Air-consumption |
0.12~0.16 m3/min |
Overall Dimension |
3400X1580X1700mm |
Net Weight |
1000Kg |
Gross Weight |
1300Kg |
Some Parts of this Machine:
Samples :
