Specifications
12mm pixel led string ws2801 chip50pcs/ string, 5V,0.3W
4 Matrix ,artnet ,arduino compatible
CE RoHS, 2 years warranty
arduino ws2801 mini 12mm diameter pixel led 50pcs a set for advertising sd controller
description:
12mm 5V WS2801 Square RGB LED Digital Pixel Light
RGB Pixels are digitally-controllable lights you can set to any color, or animate. Each RGB LED and controller chip is molded into a 'dot' of silicone. The dots are waterproof and rugged. There are four flanges molded in so that you can 'push' them into a 12mm drill hole in any material up to 1.5mm/0.06" thick. They're typically used to make outdoor signs. Compared to our other 20mm LED dots, these are diffused 8mm LEDs so they are not as bright but they color mix a little nicer.
feature:
SD controller
WS2801 IC, Programable by Software, Individually Control
Conformal Coating,PVC glue protection, IP67, Water-proof protection
Easy installation (punching 12mm hole on metal panel)
50pcs per set, single led play rgb pixel light string 12mm
* LED pixel protruding design make a broader perspective;
* High brightness with 6000CD/sqm ensure the complete outdoor use;
* Durable cover with plastic fabric raw material imported from German
Note: There are no labels on the wires. You can look at the example code or hook it up as follows:
clock - blue, data - green, red - DC5V, yellow - GND.
There is a black arrow on the underside of the LEDs which indicates the direction of the strand.
Specification:
Model NO. |
SJ-12-ICRGB |
IC chip |
WS2801, ws2811, ucs1903, lpd6803, sm16716 |
Power Consumption |
0.3W |
Work Voltage |
DC 5V |
Beam Angle |
≥120 |
LED Quantity |
1 pcs F8 strawhat lamp |
Color |
Full color (ICRGB), |
Dimension |
12mm |
Waterproof Grade |
IP65/IP67 |
controller |
SD,DMX512,Arduino |
Life-span |
50,000H |
Certificate |
CE&RoHS |
Warranty |
2 years |
Applications:
1. Lights, back lights, cabinet lights, edge light, architectural lights for corridor, canopy, archway, lights for paty and contour marking; etc.
2.They can be a good choice for advertising,Led screen, night clubs, coffee / wine bars, shopping malls,
various shops, cinemas, beauty centers, office fronts, even lights for household kitchens or living rooms, etc.
Here's a link on youtube used the arduino rgb square 12mm ws2801 led pixel light.
/watch?v=yya_IB6S-Ko
Detail pictures:
Two types: Round shape and square shape 12mm pixel led.
Various kinds of IC chip, like WS2801, ws2811, ucs1903, lpd6803, sm16716.
50pcs/string and customer size available.
Controller: DMX controller & decoder & SD controller & arduino controller
Two male and female connectors on each end of the string.
Project with the 12mm pixel led. Every led change color individually.
Package: 50 pcs per string 250 pcs per bag ;2000 pcs per carton.
