<h2>dc5v Digital RGBW LED Strip White PCB 60 LED/m sk6812</h2>
Technical details:
3. Thickness of strip (w/ waterproofing): ~4.2mm / 0.16"
4. Removable IP65 weatherproof casing, and IP20 with 3M adhesive tape
5. Maximum 5V @ 80mA draw per LED (all LEDs on full brightness)
6. 5VDC power requirement (do not exceed 6VDC) - no polarity protection
7. 1 integrated RGB LEDs per segment, individually controllable
8. Neutral white color temperature: ~4000-4500K
warm white color temperature: ~2800-3000K
cold white color temperature : ~6000K
Control System for RGBW SK6812 pixel addressable led strip:
1. Offline control: SJ-K-1000G SD card controller, arduino, dmx artnet controller.
2. Compatible with Arduino, DMX 512, dmx controller
Connection:
1. Signal wire: DC+, DAT, GND
2. DC+ and GND connect to power supplier;DAT and GND connect to controller
3. Relative Controller: SPI controller support SK6812; when use DMX decorder, can connect to DMX system
4. Support online control
5. non-waterproof and waterproof power supply also avaliable
6. RGBW 4channel built in one SMD5050 LED lamp to make it addressable
Appalications:
1. Edge lighting
2. Cabinet lighting
3. Cove lighting
4. Wall color wash lighting
5. Residential kitchens
6. Decorative lights for holiday, event, show, exhibition
7. Automobile and bicycle decoration
8. outdoor and indoor decoration
Specifications for ws2801 led strip:
| Item: | dc5v Digital RGBW LED Strip White PCB 60 LED/m sk6812 |
| led quantity: | 30led/m,5m/roll |
| led voltage: | DC5V |
| power consumption: | 9.6w/m |
| LED chip: | epistar smd 5050 |
| IC chip: | sk6812 IC |
| IP grade: | IP20,IP65silicone tube,IP67,IP68 |
| PCB color: | white /black PCB |
| LED viewing angle: | 120degree |
| Standard length: | 5m/roll or customized |
| led controller: | k-1000G,dmx controller,arduino, madrix software |
| PCB width: | 10mm |
| Certifications: | CE&Rohs |
detailed images for RGBW SK6812 pixel addressable led strip:
rgbw sk6812 144led pixel addressable led strip:
