Large Duty Piano Hinge With 60mm Open Width 3mm Thickness

Large Duty Piano Hinge With 60mm Open Width 3mm Thickness thumbnail-1
Large Duty Piano Hinge With 60mm Open Width 3mm Thickness photo-1
US$ 0.39 - 39.89 MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NTS
Model Number:
CY42
Contact Supplier Request Quote Chat Now
Foshan Nanhai Chengyi Hardware Product Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name NTS
Model Number CY42

Specifications

heavy duty stainless steel piano hinges,
length: 2438mm
thickness:3m
open width:60mm,76mm,100mm,150mm,200mm
9mm pin diameter

  large duty piano hinge with 60mm open width 3mm thickness

Find us on line or by mail right now!

Get the lowest and newest prices!!

Chengyi Hardware, as a professional manufacturer and supplier, is specialized in developing, producing and marketing furniture fittings all over the world.

We are specialized in manufacturing piano hinges, heavy duty train hinges, long hinges, cabinet/box furniture hinges, shelf brackets and upright post, pipes and tubes... vary kinds of hardware fittings in China.

And we have been in this line more than 10 years. We can supply above mentioned items or design new for your special requirements.

large duty piano hinge with 60mm open width 3mm thickness



Item No.

Length*Width*Thickness

Pin diameter

 Joint Length

CY42

2438*60*3.0MM

9MM

25.4MM



Material:stainless steel 201

Finish:polished/brushed

Holes: with or without

large duty piano hinge with 60mm open width 3mm thicknesslarge duty piano hinge with 60mm open width 3mm thickness

large duty piano hinge with 60mm open width 3mm thickness

 Following are some of our factory standard sizes!

The length can be changed shorter or longer!

Item No.

length*width*thcikness

Pin Diameter

Joint Length



Item No.

length*width*thcikness

Pin Diameter

Joint Length

CY01

1800*25*0.5MM

2.50

12.70



CY24

1800*76*1.5MM

4.00

25.4

CY02

1800*30*0.5MM

2.50

12.70



CY25

1800*38*1.5MM

5.00

25.4

CY05

1800*25*0.8MM

2.50

12.70



CY26

1800*50*1.5MM

5.00

25.4

CY06

1800*30*0.8MM

2.50

12.70



CY27

1800*63*1.5MM

5.00

25.4

CY07

1800*38*0.8MM

2.50

12.70



CY28

1800*76*1.5MM

5.00

25.4

CY08

1800*50*0.8MM

2.50

12.70



CY29

2000*50*2.0MM

6.00

25.40

CY09

1800*25*1.0MM

2.50

12.70



CY30

2000*60*2.0MM

6.00

25.40

CY10

1800*30*1.0MM

2.50

12.70



CY31

2000*76*2.0MM

6.00

25.40

CY11

1800*38*1.0MM

2.50

12.70



CY32

2000*100*2.0MM

6.00

25.40

CY12

1800*50*1.0MM

2.50

12.70



CY33

2000*50*2.0MM

9.00

25.40

CY13

1800*30*1.2MM

3.00

25.4



CY34

2000*60*2.0MM

9.00

25.40

CY14

1800*38*1.2MM

3.00

25.4



CY35

2000*76*2.0MM

9.00

25.40

CY15

1800*50*1.2MM

3.00

25.4



CY36

2000*100*2.0MM

9.00

25.40

CY16

1800*63*1.2MM

3.00

25.4



CY37

2438*60*3.0MM

6.00

38.00

CY17

1800*38*1.5MM

3.00

25.4



CY38

2438*76*3.0MM

6.00

38.00

CY18

1800*50*1.5MM

3.00

25.4



CY39

2438*100*3.0MM

6.00

38.00

CY19

1800*63*1.5MM

3.00

25.4



CY40

2438*150*3.0MM

6.00

38.00

CY20

1800*76*1.5MM

3.00

25.4



CY41

2438*200*3.0MM

6.00

38.00

CY21

1800*38*1.5MM

4.00

25.4



CY42

2438*60*3.0MM

9.00

38.00

CY22

1800*50*1.5MM

4.00

25.4



CY43

2438*76*3.0MM

9.00

38.00

CY23

1800*63*1.5MM

4.00

25.4



CY44

2438*100*3.0MM

9.00

38.00



 large duty piano hinge with 60mm open width 3mm thickness

large duty piano hinge with 60mm open width 3mm thickness

We supply not only standard but also the special  shorter or longer!

Please check more details here:

Material

steel,stainless steel 201/304/316,iron,brass,aluminium …

Finish

material nature color,brushed,polished,mirror,colored zinc/copper/blue zinc/nickel/gold/ brass/chrome/zinc plated, white /black/gold/baige/grey color spray painting

Overall length

from 20mm-6000mm (0.7" ,to 236")

Overall width

from 15mm-150mm (0.5",1"',1.2",1.5",2",2.5",3",4",6,8")

Thickness

from 0.5mm-3.0mm (0.02",0.03",0.04",0.05",0.06",0.8",0.12")

Packing specification

For the short hinges:20 pcs /white plastic bag,10 bags /carton

For the long hinges:20 piece /white plastic bag,3 plastic bag/knit bag ,special packing is acceptable.

Terms of Transaction:

Full advance payment before shipment.

Immediate delivery upone receipt of payment, please always check stock status or lead time prior ordering.

Over charged sample value can be deducted from bulk purchase,

By T/T

 large duty piano hinge with 60mm open width 3mm thickness

 large duty piano hinge with 60mm open width 3mm thickness       large duty piano hinge with 60mm open width 3mm thickness



 large duty piano hinge with 60mm open width 3mm thickness       large duty piano hinge with 60mm open width 3mm thickness

large duty piano hinge with 60mm open width 3mm thickness      large duty piano hinge with 60mm open width 3mm thickness

  large duty piano hinge with 60mm open width 3mm thickness

  1. More than 10 years experience
  2.  Automatic production line
  3. Adopt good raw material as customers' required
  4. Quality: SGS test, passed 75 pounds load, passed over 50,000 pen-close, passed salt and mist for over 48 hours
  5. Finish: brass plated, nickel plated, antirust oil, rustproof more efficiently.
