Cold work mould steel 1.2436
1.Chemical Composition(%)
| Standard | Grade | C | Si | Mn | Cr | W | Mo | V | P | S | Other |
| China GB | Cr12W | 2.00-2.25 | 0.10-0.40 |
0.15-0.45 | 11.00-12.00 | 0.60-0.80 | ≤0.030 | ≤0.030 | Co≤1.00 | ||
| American AIS | |||||||||||
| Germany DIN | 1.2436 | 2.00-2.25 | 0.10-0.40 | 0.15-0.45 | 11.00-12.00 | 0.60-0.80 | ≤0.030 | ≤0.30 | Co≤1.00 | ||
| Janpan JIS | SKD2 | 2.00-2.30 | 0.10-0.40 | 0.30-0.60 | 11.00-13.00 | 0.60-0.80 | ≤0.030 | ≤0.030 |
2. Available sizes :
Rolled flat bar Thickness 8-60mm width:600-610mm rolled Round bar dia. 50-130mm
Forged flat bar Thickness:60-200mm width:100-800mm Forged round bar dia. 50-400mm
3 Annealed hardness :≤255HBS
4 Properties
• excellent compressive strength and good hardenability
• high wear resistance
• Resistance to plastic deformation
• cracking and chipping resistance
5 Applications
It Is widely used for manufacture of cutting tools, blanking and punching tools. Machine knives, threading tools. etc.
Furnce material-melting-steel ingot-forging-forging billet-heating-rolling-slow cooling-collecting-annealing-finishing-inspection-package-warehousing
8 Delivery condition
Annealed + black/peeled/turned/grinding/polishing surface option, UT test accord with SEP1921-84 class c/c or d/d
