Inverter Tig Welding Machine TIG-200A
US$ 100 - 300
MOQ: 20 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
FIL-TECH
Model Number:
TIG-200A
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
FIL-TECH
Model Number
TIG-200A
Arc Current
200a
Pulse Frequency
50
Pilot Arc Current
200
Rated Duty Cycle
60%
Dimensions
37cm*15.5cm*29.5cm
Usage
argon and stick welding
Specifications
inverter tig welding machine* inverter DC mma & tig welder
* MOSFET
*CE certificate
inverter tig welding machine
FEATURES:
♦Adopt advanced MOSFET technology,energy-saving.
♦Two functions of TIG/MMA,economic and practical .
♦With PWM pulse width modulation technology,HF arc starting,stable current,the first choice for thin plate welding.
♦With perfect over-current and over voltage protection function,safty and durable.
♦Mainly used in welding carbon steel,stainless steel,alloy steel and copper.
"♦Accessories: TIG torch,electrode holder,earth clamp,brush/hammer,protective mask,carton box.
|
TIG-130A | TIG-160A | TIG-180A | TIG-200A | |
| Input Voltage | 1PH 230V | 1PH 230V | 1PH 230V | 1PH 230V | |
| Frequency | 50/60Hz | 50/60Hz | 50/60Hz | 50/60Hz | |
| Rated Input Capacity | 4.1KVA | 5.3KVA | 6.2KVA | 7.1KVA | |
| Max No-load Voltage | 60V | 60V | 60V | 60V | |
| Current Range | 10-130A | 10-160A | 10-180A | 10-200A | |
| Rated Duty Cycle | 60% | 60% | 60% | 60% | |
| Insulation Class | F | F | F | F | |
| Rated work voltage | 25.2V/MMA | 26.4V/MMA | 27.2V/MMA | 28V/MMA | |
| Efficiency | 85% | 85% | 85% | 85% | |
| Power Factor | cosφ0.93 | cosφ0.93 | cosφ0.93 | cosφ0.93 | |
| Protection Degree | IP21S | IP21S | IP21S | IP21S | |
| Cool Type | Fan | Fan | Fan | Fan | |
| Dimension | 41x26x33CM | 45x26x33CM | 45x26x33CM | 45x26x33CM | |
| Weight | 7.0KG | 8.7KG | 8.7KG | 8.8KG |
