custom steel pneumatic components investment casting

as per your demand

Specifications

custom steel pneumatic components investment casting
ISO9001:2000 Approved
Process:investment casting
Standard:JIS,DIN,ASTM

custom steel pneumatic components investment casting

we can offer you investment casting parts.

If you are interested in our company, please kindly send us your detailed information such as drawing, specification, chemical composition and so on, we would like to provide you OEM service.

1.OEM service available

2.Materials: stainless steel,carbon steel,low alloy steel and so on

3.Process: investment casting

4.Weight range: 0.02 to 30kg

5.Application:gun ,  pneumatic parts.

6.Small orders accepted

7.make  machining service as your requirement or drawings

fessional service
9.surface treatment,polishing,machining,machining center,plating,Heat Treatment,etc.

steel pneumatic components investment casting specification
Equipment	cnc milling machine, CNC machining center etc;
Drawing soft ware used	UGPRO-ESOLIDWORKERS2010CAD etc;
Inspection equipment	Three-coordinates measuring machine,Hardness-testing device,spectrum analyzer;
Material	carbon steel, stainless steel,low alloy steel etc;
Machining precision	±0.01mm
Weight range	0.02-30kg
Surface treatment	plating,anodizing powder coating,spray-paint,electrophoresis;
Delivery time	30 days after confirmed the order (According to order quantity );
Service	OEM/ODM service are welcome
Standard	DIN,AISI,ASTM,BS,JIS,etc
Certification	ISO9001:2000
Packaging	Carton, Iron Pallets,Wooden Pallets, Or as your demand!
Payment Terms	T/T
MOQ	small order is acceptable
Application	gun, pneumatic parts ,Industrial parts,Machinery parts,construction parts,valve parts,train,craft,hydraulic pressure,agricultural machinery,Marine hardware,Auto parts,electric power fittings,food machinery,harness fittings,tools,mining machinery parts .
process	Casting,CNC Machining,other process can be customized



Process		Suitable  Material
Sand Casting	Green Sand	Grey Iron, Ductile Iron, Malleable Iron, Stainless Steel, Carbon Steel, Aluminium,Copper, Brass,Bronze
	Furan Resin Sand
	Cold Harden Resin Sand
Investment Casting	Soluble glass casting (Water Glass casting)	Stainless Steel, Carbon steel, Low Alloy Steel, Brass,Brone, Aluminium
	Silica Sol casting
	Lost-foam casting
	Combining silica sol casting process with soluble glass casting
Forging,Powder metallurgy	Hammer Forging	Stainless Steel, Carbon Steel, Alloy Steel,Brass, Aluminium
	Die Forging
	Roll Forging
Stamping		All Metal Material
Machining		All Metal Material
Die casting		Aluminum alloy,zinc alloy,zinc,aluminum





Investment casting is an industrial process based on and also called Lostwax casting, one of the oldest

known metal-forming techniques. The Investment Casting process begins with producing a heat disposable

pattern. This is accomplished by injecting wax into a metal die. A pattern must be molded for every casting.

These patterns are assembled into a cluster (or tree) and are then coated with various liquid ceramic refractories to form a ceramic shell. The wax is then melted out of the ceramic shell. Any number of different alloys can be cast into the ceramic mold. After cooling, the ceramic shell is removed and the castings are cleaned.

Our investment casting process:

a)Silicasol casting process( maintains typical tolerance accuracy within CT4-CT6 standard,

with a surface finish of Ra3.2-6.4)

b)Soluble glass casting process(maintains typical tolerance accuracy within CT7-CT9 standard,

with a surface finish of Ra12.5)

c)Lost-foam casting process

d)Combining silica sol casting process with soluble glass casting process:

the price is lower than silica sol casting process, and higher than soluble glass casting process; the quality is also in the middle of this 2 processes.

Suitable Material: stainless steel, carbon steel, and low alloy steel.
